General information:
Revision 1.3 - 7 -
Mounting Notes:
Read and clearly understand manual BEFORE beginning ANY work
Important!!!
The basic rule of PALFINGER Liftgates ILP installation is to raise mount frame
to achieve MAXIMUM ground clearance WITHOUT exceeding Min “F” dimension.
• Refer to mounting tables and determine the proper [S] dimension.
o If the sill is greater than what’s allowed, the sill has to be notched and capped to achieve
original strength.
• Bend flat bar and weld 100% around the notch.
• Minimum bed height dimensions are ALWAYS MAXIMUM LOADED TRUCK
• Floor Height Ranges: Max=Unloaded; Min=Loaded
• Installing a gate at or close to minimum bed height normally results in a
gate that will NOT open and close from stored position if the floor height
goes below minimum bed height when truck is loaded.
Call tech support before starting the installation if you have any questions or concerns
on mounting dimensions 888-774-58
