PTV 35/44/55/66 Installation Manual
Rev. 1.1 36
6. Remove Forklift Fork, Bracing and Clamps: First remove the forklift. Second remove the clamps, and
finally remove the liftgate braces.
Remove all
clamping
devices
Unbolt
Top
Brace
4X
Remove
Top Brace
Remove all
clamping
devices
Remove
Bottom
Brace
Remove
Forklift
7. Gate Mounting Complete: Standard lifegate mounting is now complete, proceed to hydraulic installation.
