32
V
RATINGS
█
1-Phase 200V input type
Model AMK300 □□□ 2 0P2 0P4 0P7 1P5 2P2
Standard specificaion
Applicable motor output(kW) *1
0.2 0.4 0.75 1.5 2.2
Rated output current(A) *2
1.5 3.0 5.0 8.0 11.0
Rated output capacity(kVA) *3
0.6 1.2 2.0 3.2 4.4
Rated input current(A) *4
3.9 8.0 12.6 18.5 23.8
Power supply capacity(kVA) *4
0.9 1.8 2.9 4.3 5.5
Light load specificaion
Applicable motor output(kW) *1
0.4 0.75 1.5 2.2 3.0
Rated output current(A) *2
1.9 3.5 6.0 9.6 12.0
Rated output capacity(kVA) *3
0.8 1.4 2.4 3.8 4.8
Rated input current(A) *4
5.1 9.1 15.2 22.3 25.8
Power supply capacity(kVA) *4
1.2 2.1 3.5 5.1 5.9
Weight (kg)
Approx.
1.0
Approx.
1.0
Approx.
1.4
Approx.
1.6
Approx.
2.0
█
3-phase 400V input type
Model AMK300 □□□ 4 0P7 1P5 2P2 3P7 5P5 7P5 011 015
Standard specificaion
Applicable motor output(kW) *1
0.75 1.5 2.2 3.7 5.5 7.5 11.0 15.0
Rated output current(A) *2
2.6 4.0 6.0 9.5 12.0 17.0 23.0 31.0
Rated output capacity(kVA) *3
2.1 3.2 4.8 7.6 9.6 13.5 18.3 24.7
Rated input current(A) *4
3.9 6.0 9.0 14.3 15.6 22.1 29.9 40.3
Power supply capacity(kVA) *4
3.1 4.8 7.2 11.4 12.4 17.6 23.8 32.1
Light load specificaion
Applicable motor output(kW) *1
1.5 2.2 3.7 5.5 7.5 11.0 15.0 18.5
Rated output current(A) *2
3.6 5.4 6.9 11.1 17.0 17.0 31.0 38.0
Rated output capacity(kVA) *3
2.9 4.3 5.5 8.8 13.5 13.5 24.7 30.3
Rated input current(A) *4
5.4 8.1 10.4 16.7 22.1 22.1 40.3 49.4
Power supply capacity(kVA) *4
4.3 6.5 8.2 13.3 17.6 17.6 32.1 39.4
Weight (kg)
Approx.
1.5
Approx.
1.6
Approx.
1.9
Approx.
2.0
Approx.
3.6
Approx.
3.6
Approx.
8.2
Approx.
8.3
*1 " Applicable motor output" refers to the maximum applicable capacity of standard
4-pole motor. Make sure that the rated output current of inverter is higher than the
rated current of motor during inverter selection.
*2 The rated output current of inverter varies with the set carrier frequency. Derate the
output current as shown in the following figure.
*3 Rated output capacity refers to the value at output voltage of 230V AC for 1-phase
200V input type and the value at output voltage of 460V AC for 3-phase 400V input
type.
*4 The input current and the power supply capacity varies with the impedance at
its side. Prepare the power supply with capacity larger than values shown in the
above table.
