Panasonic AMK3003P74 - Common Specifications

35
█
Common specifications
Item Specifications
Output frequency
Frequency
range
VF control: 0.2Hz to 400Hz
Sensorless vector control: 0.5Hz to 120Hz
Frequency
display
Digital display
Frequency
precision
Analog setting: within ±0.5% of maximum set frequency (25℃ ±
10℃ )
Digital setting: within ±0.01% of maximum set frequency (-10℃ to
+ 50℃ )
Frequency
resolution
Analog setting : 0.1Hz (in 50/60Hz mode)
Digital setting : 0.1Hz
Inverter control
mode
High carrier frequency sinusoidal PWM control
(V/F control or sensorless vector control is available.)
Carrier frequency
· V/F control setting: 9 options (adjustable from 0.8kHz to 15kHz)
can be selected.
· Sensorless vector control setting: 6 options (adjustable from
2.5kHz to 15kHz) can be selected. (0.8kHz, 1.1kHz, 1.6kHz,
2.5kHz, 5.0kHz, 7.5kHz, 10.0kHz, 12.5kHz, 15.0kHz)
Operation
Start/Stop
· Operation panel buttons
· 1a contact signal and 3-wire input (1a and 1b contact signals) can
be selected.
· RS485 communication
· Wait time (0.1s to 100s) can be set.
Forward/
Reverse run
· Operation panel buttons
· 1a contact signal (reverse run can be disabled.)
· RS485 communication
Jogging
operation
Operating frequency: adjustable from 0.2Hz to 400Hz
Acceleration/deceleration time: adjustable from 0.04s to 3600s
Stop mode Deceleration stop / coast-to-stop (switchable)
Reset
function
Reset by stop signal/reset by external devuce/reset by
operation panel(optional) / reset by power supply
Starting
frequency
Adjustable from 0.2Hz to 60Hz
Stop
frequency
Adjustable from 0.2Hz to 60Hz
Ride-through
restart
selection
0Hz restart/operation frequency restart/speed search restart
(switchable)
Speed
search
Speed search during startup (optional)
Retry
function
Retry selection: validity of function, selection of details of retry
faults
Retry operations: adjustable from 1 to 10 operations
