Panasonic AMK3003P74 - Function

49
No. Function name
Changes
during RUN
Setting range Unit
Initial
value
P122
PWM/Pulse
Output Function
Selection
○
0: Output frequency
1: Output current
－ 0
P123
PWM Output
Cycle
○ 1 to 2000 1[msec] 1
P124
Output TR1
Function
Selection
○
0: Run signal
1: Reverse run signal
2: Arrival signal
3: Overload alarm
4: Frequency detection
5: Current detection (1)
6: Current detection (2)
7: Fault alarm (1)
8: Fault alarm (2)
9:
Timer operation stop after one cycle
10: Timer operation stop
11: Alarm
12: Speed search operation
13: PWM output
14: Pulse train output
－ 0
P125
Output TR2
Function
Selection
○
0: Run signal
1: Reverse run signal
2: Arrival signal
3: Overload alarm
4: Frequency detection
5: Current detection (1)
6: Current detection (2)
7: Fault alarm (1)
8: Fault alarm (2)
9:
Timer operation stop after one cycle
10: Timer operation stop
11: Alarm
12: Speed search operation
－ 0
P126
Output RY
Function
Selection
○
(*3)
0(r0): Run signal
1(r1): Reverse run signal
2(r2): Arrival signal
3(r3): Overload alarm
4(r4): Frequency detection
5(r5): Current detection (1)
6(r6): Current detection (2)
7(r7): Fault alarm (1)
8(r8): Fault alarm (2)
9(r9): Timer operation stop after
one cycle
10(r10): Timer operation stop
11(r11): Alarm
12(r12): Speed search operation
－ 0
