48
No. Function name
Changes
during RUN
Setting range Unit
Initial
value
P109
PWM Signal
Average Times
○ 1 to 100 1[times] 1
P110
PWM Signal
Cycle
○ 1.0 to 2000
0.1[msec]
1.0
P111
Analog Input
Filter
○ 5 to 200 1[times] 10
P112
Bias Frequency
Setting
○ –99.0 to 250.0 0.1[%] 0.0
P113
Gain Frequency
Setting
○ 0.0 to 500.0 0.1[%] 100.0
P114
Analog Direction
Mode
○
0: No setting
1: Analog input can be reversed.
(Forward → Reverse)
2: Analog input can be reversed.
(Reverse → Forward)
- 0
P115
2nd Bias
Frequency
Setting
○ –99.0 to 250.0 0.1[%] 0.0
P116
2nd Gain
Frequency
Setting
○ 0.0 to 500.0 0.1[%] 100.0
P117
2nd Analog
Direction Mode
○
0: No setting
1: Analog input can be reversed.
(Forward → Reverse)
2: Analog input can be reversed.
(Reverse Forward)
- 0
P118
2nd Analog Input
Function
Selection
-
0: 2nd frequency setting signal
1: Measured value of PID control
(PV)
2: Base frequency + PID adjusted
value
3: Base frequency + Auxiliary
frequency setting signal
- 0
P119
2nd Analog Input
Signal
Selection
-
2 :External control,0V to 5V
3 :External control,0V to 10V
4 :External control,4mA to 20mA
5 :External control,0mA to 20mA
- 2
P120
Analog Output
Function
Selection
○
0: Output frequency
1: Output current
- 0
P121
PWM Output
Duty Ratio
Compensation
○ 25 to 100 1[%] 100
