47
No. Function name
Changes
during RUN
Setting range Unit
Initial
value
P105
SW5 Function
Selection
－
(*2)
0: No setting
1(r1): Multi-step speed
2(r2): Reset
3(r3): Reset lock
4(r4): Jogging selection
5(r5): Stop by external fault
6(r6): Parameter setting disabled
7(r7): Coast-to-stop
8(r8): Switching of frequency signal
9(r9): 2nd characteristics selection
10(r10): Switching of PID control
11(r11): 3-wire stop command
12(r12): Speed search
13(r13): Winding mode pause
14(r14): Winding length input mode
15(r15): Winding length clear
16(r16): Run/stop
17(r17): Forward/reverse run
18(r18): Forward run by jogging
19(r19): Reverse run by jogging
20(r20): Frequency memory setting
－ 0
P106
SW6 Function
Selection
－
(*2)
0: No setting
1(r1): Multi-step speed
2(r2): Reset
3(r3): Reset lock
4(r4): Jogging selection
5(r5): Stop by external fault
6(r6): Parameter setting disabled
7(r7): Coast-to-stop
8(r8): Switching of frequency signal
9(r9): 2nd characteristics selection
10(r10): Switching of PID control
11(r11): 3-wire stop command
12(r12): Speed search
13(r13): Winding mode pause
14(r14): Winding length input mode
15(r15): Winding length clear
16(r16): Run/stop
17(r17): Forward/reverse run
18(r18): Forward run by jogging
19(r19): Reverse run by jogging
20(r20): Winding length
－ 0
P107
Pulse Train Input
Frequency
－ 1.0 to 40.0 1[kHz] 1.0
P108
Pulse Train Input
Filter
－ 10 to 100 1[times] 50
