40
No.
Function
name
Changes
during RUN
Setting range Unit
Initial
value
P005
Operation
Status
Monitor
－
0: Output frequency
1: Linear speed
2: Output current
3: Communication station
No.
4: Setting frequency
5: Communication station
No./Output frequency
6: Communication station
No./Linear speed
7: Communication station
No./Output current
8: Winding length
－ 0
P006
Vector
Control
Selection
－
0: V/F control
1: Sensorless vector control
－ 0
P007
Carrier
frequency
○
During V/F control: 0.8 to 15.0 (9 steps)
During sensorless vector control: 2.5 to 15.0 (6 steps)
[kHz] 2.5
P008
S-shaped
Acceleration
/Deceleration
Mode
－
0: Linear acceleration/deceleration
1: S-shaped acceleration/deceleration (Quadratic
curve)
2: S-shaped acceleration/deceleration (Cubic curve)
－ 0
P009 V/FMode －
50 ：50Hz mode
60 ：60Hz mode
FF ：Free mode
3C ：3-point type
3C1 ：3-point fixing 1
3C2 ：3-point fixing 2
3C3 ：3-point fixing 3
3C4 ：3-point fixing 4
3C5 ：3-point fixing 5
3C6 ：3-point fixing 6
－ 50
P010 V/FCurve －
0: Constant torque mode
1: Reduced torque mode
－ 0
P011
Torque
Boost*7
○
0 to 40: Manual torque boost
Auto: Automatic torque boost
1[%] *4
P012
Maximum
Output
Frequency
－ 50.0 to 400.0 0.1[Hz] 50.0
P013
Base
Frequency
－ 45.0 to 400.0 0.1[Hz] 50.0
P014
Change
Point
Frequency
1
○ 0.2 to 400.0 0.1[Hz] 0.2
P015
Change
Point
Voltage 1
○ 0.0 to 100.0 0.1[%] 0.0
P016
Change
Point
Frequency
2
○ 0.2 to 400.0 0.1[Hz] 0.2
P017
Change
Point
Voltage 2
○ 0.0 to 100.0 0.1[%] 0.0
P018
Maximum
Output
Voltage
－ 0(Power supply voltage), 1 to 500 1[V] 0
P019
JOG
Frequency
○ 0.2 to 400.0 0.1[Hz] 10.0
