Panasonic AMK3003P74 - P3 Parameter Settings

53
No. Function name
Changes
during RUN
Setting range Unit
Initial
value
P223
Exciting Inductance
of 2nd Motor
0.0 to 999.9, 1000 to 5000 (in increments of
1 mH)
0.1[mH] *4
P224
Leakage Inductance
of 2nd Motor
0.0 to 999.9 0.1[mH] *4
P225
Exciting Current of
2nd Motor
0.01 to 99.99 0.01[A] *4
P226
Speed Control
Proportion Amplitude
of 2nd Motor
0.01 to 10.00 0.01 *4
P227
Speed Control
Integral Amplitude of
2nd Motor
0.01 to 10.00 0.01 *4
P228
Torque Limit Level of
2nd Motor
50 to 400 1[%] *4
█
P3 Parameter List
No. Function name
Changes
during RUN
Setting range Unit
Initial
value
P301
Multi-step Speed
Function Selection
－
0: Multi-step speed frequency operation
1: 2nd/3rd/4th acceleration/deceleration
function
2: Acceleration/deceleration linked with
multi-step speed frequency operation
3: Multi-step speed frequency operation
by timer
4: Aceleration/deceleration linked with
multi-step speed frequency operation by
timer
－ 0
P302
2nd Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 5.0
P303
3rd Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 10.0
P304
4th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 12.5
P305
5th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 15.0
P306
6th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 17.5
P307
7th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 20.0
P308
8th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 22.5
P309
9th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 25.0
P310
10th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 27.5
P311
11th Step Speed
Frequency
○ 0.0, 0.2 to 400.0 0.1[Hz] 30.0
