Radioshack Part# 276-011
•Lens size is 5mm
•Red diffused lens color
•Viewing angle is 60°
•30mA (max)
•Typical Voltage is 12, with a maximum voltage of 12V
•One per package
•Mfg hole diameter is 5/16"
RED (+) cable connects to GPO1 (Pin#25) or GPO2 (Pin#8)
YELLOW (-) cable connects to GPIO (Pin#9) ground cable
If the User would like to see the REC/Error status from inside of vehicle
additionally, it is possible to set up the LED light connecting to GPIO
External GPIO Trigger (External LED)
