4. Power cable harness for VPU, Wireless MIC and 2
nd
camera
1. There are basically two options for the connections.
One is with Charge Guard, another is for Accessory connection
using internal timer in VPU.
2. +12V Power line:
VPU: 1) Power line (+12V : red) must be connected to the battery
through 7.5 amp fuse (not in the kit).
2) Signal line (white) must be connected to the Charge Guard or
Accessory SW though 7.5 amp fuse (not in the kit).
Wireless MiC: Power line (+12V:red) must be connected to VPU white line.
2
nd
Camera: Power line (+12V: white) also must be connected to VPU white line
3. GND line:
VPU : Power cable and Trigger cable (2 lines)
Wireless Mic : Power GND and trigger GND (2 lines)
2
nd
Camera : Power GND (1 line)
All black lines must be connected directly to the negative terminal of the battery.
