- 79 (E) -
wAW-E650, AW-E350
indicates safety information.
Source Voltage: DC 12 V Power consumption: 11.8 W (AW-E650), 11.3 W (AW-E350)
AW-E650 AW-E350
Optical system 1/2˝ prism, F1.4 1/3˝ prism, F1.4
Pick up device 1/2˝ interline-type CCD 1/3˝ interline-type CCD
Number of valid pixels
752 M 582 (approx. 440,000 pixels)
Total number of pixels
795 M 596 (approx. 470,000 pixels)
Scanning system 625 scanning lines, 50 fields, 25 frames
Synchronizing system
Internal synchronization: PAL standard;
external synchronization: BBS or VBS (BNC M 1, D-sub 50P M 1)
Video output
Composite: 1.0 V [p-p]/75 ohms (BNC M 1, D-sub 50P M 1)
Y/C Y: 1.0 V [p-p]/75 ohms; C: 0.3 V [p-p]/75 ohms (burst) (D-sub 50P M 1)
Y/Pr/Pb Y: 1 V [p-p]/75 ohms; Pr, Pb: 0.525 V [p-p]/75 ohms (D-sub 50PM 1)
RGB G: 1 V [p-p]/75 ohms; RB: 0.7 V [p-p]/75 ohms (D-sub 50P M 1)
Standard illumination,
colour temperature
2,000 lx
(F14, 3,200K)
2,000 lx
(F9.5, 3,200K)
Minimum illumination
0.00005 lx at F1.4,
Night Eye mode, 30 dB digital gain,
2s storage time, output of 70 % or above
0.00015 lx at F1.4,
Night Eye mode, 30 dB digital gain,
2s storage time, output of 70 % or above
S/N ratio 65 dB (Y signal, DTL OFF, DNR ON) 63 dB (Y signal, DTL OFF, DNR ON)
Horizontal resolution 850 TV lines (high-band DTL ON, centre area)
Registration 0.05 % (entire screen, excluding effects of lens)
Geometric distortion 0 %
Contour correction Horizontal, vertical (2H)
White balance AWC A, AWC B (R/B gain, painting), ATW, 3,200K, 5,600K preset
Black balance Auto (R/B pedestal, painting function)
Chroma amount variability 7-level variability
Encoding system OFF, Low, High
Gain selection 0 to 30 dB in steps, AGC, Night Eye L, H 0 to 30 dB in steps, AGC, Night Eye
