ENGLISH
- 80 (E) -
AW-E650 AW-E350
Electronic shutter speeds
1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000;
ELC, synchro scanner (50.24 Hz to 15.63 kHz)
CCD readout selection Field, frame1, frame2
Colour bars FULL
Lens mount 1/2˝ bayonet mount 1/3˝ C mount
Lens diaphragm Auto, Manual (but only with remote control), adjust ON, OFF
Internal filters –––
Selector switches
MENU(©)
ITEM/AWC (ª) (AWC: when menu screen is not displayed)
YES/ABC (+) (ABC: when menu screen is not displayed)
NO/BAR (–) (BAR: when menu screen is not displayed)
Input/output connectors
VIDEO OUT BNC connector
G/L IN BNC connector
IRIS 12P round connector
DC 12 V IN DC connector
I/F REMOTE 50P D-sub connector
Indicator Red LED; power ON when lit
Allowable temperature ranges
For storage: –20 °C to +60 °C
For guaranteeing performance: +5 °C to +35 °C
For guaranteeing operation: –10 °C to +45 °C
Allowable humidity ranges
For storage: 20 % to 90 %
For operation: 20 % to 90 %
Dimensions (W V H V D) 84 M 77 M 177 mm 84 M 77 M 156 mm
Mass 0.92 kg 0.77 kg
Mass and Dimensions indicated above are approximate.
Specifications are subject to change without notice.
