6
Model
Indoor CS-PC12TKF CS-PC18TKF
Outdoor CU-PC12TKF CU-PC18TKF
Dimension
Height (I/D / O/D) mm (inch) 290 (11-7/16) / 542 (21-11/32) 302 (11-29/32) / 619 (24-3/8)
Width (I/D / O/D) mm (inch) 799 (31-15/32) / 780 (30-23/32) 1102 (43-13/32) / 824 (32-15/32)
Depth (I/D / O/D) mm (inch) 197 (7-3/4) / 289 (11-13/32) 244 (9-5/8) / 299 (11-25/32)
Weight Net (I/D / O/D) kg (lb) 8 (18) / 35 (77) 12 (26) / 36 (79)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5.0 (16.4) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 30 (98.4)
I/D & O/D Height different m (ft) 5 (16.4) 20 (65.6)
Additional Gas Amount g/m (oz/ft) 10 (0.1) 20 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16.0 16.0
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre coated) Aluminium (Pre coated)
Fin Type Slit Fin Slit Fin
Row × Stage × FPI 2 × 15 × 17 2 × 17 × 17
Size (W × H × L) mm 610 × 315 × 25.4 836 × 357 × 25.4
Outdoor
Heat
Exchanger
Fin Material Aluminium (Blue coated) Aluminium (Blue coated)
Fin Type Corrugate Fin Slit Fin
Row × Stage × FPI 1 × 20 × 17 1 × 28 × 17
Size (W × H × L) mm 22 × 508.0 × 708.4 12.7 × 588.0 × 865.3
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 15 16
Thermostat - -
Protection Device - -
DRY BULB WET BULB DRY BULB WET BULB
Indoor Operation Range
Maximum
°C (°F)
32 (89.6) 23 (73.4) 32 (89.6) 23 (73.4)
Minimum
°C (°F)
16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
Outdoor Operation Range
Maximum
°C (°F)
55 (131) 31 (87.8) 55 (131) 31 (87.8)
Minimum
°C (°F)
16 (60.8) 11 (51.8) 16 (60.8) 11 (51.8)
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19.0°C Wet Bulb (66.2°F Wet Bulb) and outdoor air
temperature of 35°C Dry Bulb (95°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb).
2.
Specifications are subjected to change without prior notice for further improvement.
