Panasonic CS-PC12TKF User Manual

7
Model
Indoor CS-PC24TKF
Outdoor CU-PC24TKF
Performance Test Condition ISO 5151 (T1)
Power Supply
Phase, Hz Single, 50
V 220 240
Cooling
Capacity
kW 7.03 7.03
Btu/h 24000 24000
kJ/h 25310 25310
Running Current A 12.4 12.3
Input Power W 2.57k 2.70k
EER
W/W 2.74 2.60
Btu/hW 9.34 8.89
Power Factor % 94 91
Indoor Noise (H / L)
dB-A 48 / 42 49 / 42
Power Level dB 61 / - 62 / -
Outdoor Noise (H / L)
dB-A 57 / - 58 / -
Power Level dB 72 / - 73 / -
Max Current (A) / Max Input Power (W) 16.8 / 3.64k
Starting Current (A) 59.0
Compressor
Type Hermetic Motor / Rotary
Motor Type Induction (2 poles)
Output Power W 2.0k
Indoor Fan
Type Cross-Flow Fan
Material ASG33
Motor Type DC Motor (8 poles)
Input Power W 94.8 94.8
Output Power W 40
Speed
QLo rpm 910
Lo rpm 1000
Me rpm 1100
Hi rpm 1220
SHi rpm 1300
Outdoor Fan
Type Propeller Fan
Material PP Resin
Motor Type AC / Induction (6 poles)
Input Power W 157.3 173.8
Output Power W 88
Speed
Lo rpm 440 500
Hi rpm 860 890
Moisture Removal L/h (Pt/h) 4.0 (8.5)
Indoor Airflow
QLo m
3
/min (ft
3
/min) 15.7 (556)
Lo m
3
/min (ft
3
/min) 17.3 (611)
Me m
3
/min (ft
3
/min) 19.0 (672)
Hi m
3
/min (ft
3
/min) 21.1 (745)
SHi m
3
/min (ft
3
/min) 22.5 (794)
Outdoor
Airflow
Lo m
3
/min (ft
3
/min) 26.6 (941) 30.3 (1073)
Hi m
3
/min (ft
3
/min) 52.0 (1840) 54.0 (1910)
Refrigeration
Cycle
Control Device Capillary Tube
Refrigerant Oil cm
3
ATMOS NM56M or Suniso 4GDID (700)
Refrigerant Type g (oz) R22, 1.28k (45.2)
