Panasonic CS-Z25YKEA - Outdoor Unit

39
6.2 Outdoor Unit
6.2.1 CU-Z25YKEA CU-Z35YKEA CU-Z42YKEA
6.2.2 CU-Z50YKEA CU-Z71YKEA
(18)
69.5 61.6
542
28939
570
22
(104.7)
67.6
780
85.5
155.2 34.3
60.5104.9
Space necessary for
installation
Anchor Bolt Pitch
320
× 570
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
1000 mm
100 mm
100 mm
(25)
7570.5
695
320
386
45
7.7
61334.7
(131)
72
875
3582
360.5
131
<Side View>
<Side View>
<Front View>
<Top View>
Unit: mm
2-way valve at Liquid side
(High Pressure)
3-way valve at Gas side
(Low Pressure)
Anchor Bolt Pitch
360.5 × 613
Space necessary for
installation
100 mm
100 mm
1000 mm
