Panasonic DMR-EH57EC

14.1.3. HDMI P.C.B.
Ref No.
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
REC - - - - 1.2 - 0 2.8 3.3 0 0 0 3.3 0 0 0 3.3 0 0 0
PLAY - - - - 1.2 - 0 2.8 3.3 0 0 0 3.3 0 0 0 3.3 0 0 0
STOP - - - - 1.2 - 0 2.8 3.3 0 0 0 3.3 0 0 0 3.3 0 0 0
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
REC 3.3 0 0 0 3.3 1.2 0 3.3 - - - - 1.5 3.3 1.3 0 0 1.3 0 3.3
PLAY 3.3 0 0 0 3.3 1.2 0 3.3 - - - - 1.5 3.3 1.3 0 0 1.3 0 3.3
STOP 3.3 0 0 0 3.3 1.2 0 3.3 - - - - 1.5 3.3 1.3 0 0 1.3 0 3.3
Ref No.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
REC 1.71.21.601.601.200003.3001.200000
PLAY 1.71.21.601.601.200003.3001.200000
STOP 1.7 1.2 1.6 0 1.6 0 1.2 0 0 0 0 3.3 0 0 1.2 00000
Ref No.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
REC 000 - - 00003.300001.200000
PLAY 000 - -00003.300001.200000
STOP 0 0 0 - - 00003.300001.200000
Ref No.
MODE 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100
REC 0 0 0 3.3 1.2 0 1.8 0.9 1.1 1.4 0 0.8 0.9 0.9 0.9 - - - 3.3 3.3
PLAY 0 0 0 3.3 1.2 0 1.8 0.9 1.1 1.4 0 0.8 0.9 0.9 0.9 - - - 3.3 3.3
STOP 0 0 0 3.3 1.2 0 1.8 0.9 1.1 1.4 0 0.8 0.9 0.9 0.9 - - - 3.3 3.3
Ref No.
MODE 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120
REC 0 1.2 0 0 0 3.3 3.3 3.3 1.2 0 1.5 0 3.3 3.3 3.3 1.2 0 0 0 0.1
PLAY 0 1.2 0 0 0 3.3 3.3 3.3 1.2 0 1.5 0 3.3 3.3 3.3 1.2 0 0 0 0.1
STOP 0 1.2 0 0 0 3.3 3.3 3.3 1.2 0 1.5 0 3.3 3.3 3.3 1.2 0 0 0 0.1
Ref No.
MODE 121 122 123 124 125 126 127 128 1 2 3 4 5 1 2 3 4 5
REC 0.1 0 1.2 3.3 0 - - - 4.6 0 3.3 - 3.3 5.7 0 4.8 - 5.0
PLAY 0.1 0 1.2 3.3 0 - - - 4.6 0 3.3 - 3.3 5.7 0 4.8 - 5.0
STOP 0.1 0 1.2 3.3 0 - - - 4.6 0 3.3 - 3.3 5.7 0 4.8 - 5.0
Ref No.
MODE 1 2 3 4 5 12345
REC 2.5 3.2 1.2 1.2 0 - 1.6 0 1.5 3.3
PLAY 2.5 3.2 1.2 1.2 0 - 1.6 0 1.5 3.3
STOP 2.5 3.2 1.2 1.2 0 - 1.6 0 1.5 3.3
Ref No.
MODE E C B E C B E C B S D G S D G
REC 0 4.5 0 0 0 0.6 0 3.2 0 0.1 0.1 3.3 0.1 0.1 3.3
PLAY 0 4.5 0 0 0 0.6 0 3.2 0 0.1 0.1 3.3 0.1 0.1 3.3
STOP 0 4.5 0 0 0 0.6 0 3.2 0 0.1 0.1 3.3 0.1 0.1 3.3
Ref No.
MODE E C B E C B
REC 3.4 3.0 3.4 0 3.0 0
PLAY 3.4 3.0 3.4 0 3.0 0
STOP 3.4 3.0 3.4 0 3.0 0
IC56107
IC56103
IC56103
IC56103
IC56106
Q56102 Q56103
Q56104 Q56105
Q56001 Q56002 Q56101
IC56103
IC56103
IC56103
IC56103 IC56104 IC56105
14.1.4. P59001 Connector
Ref No.
MODE 1234567891011121314151617181920
REC 0000000000003.312.3 4.9 12.3 3.3 0 4.9 0
PLAY 0000000000003.312.3 4.9 12.3 3.3 0 4.9 0
STOP 0000000000003.312.3 4.9 12.3 3.3 0 4.9 0
Ref No.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
REC 3.3 5.1 3.3 5.1 5.0 3.3 2.3 3.1 2.5 4.9 2.5 3.3 0 3.3 0 3.3 0 3.3 2.5 -
PLAY 3.3 5.1 3.3 5.1 5.0 3.3 2.3 3.1 2.5 4.9 2.5 3.3 0 3.3 0 3.3 0 3.3 2.5 -
STOP 3.3 5.1 3.3 5.1 5.0 3.3 2.3 3.2 2.5 4.9 2.5 3.3 0 3.3 0 3.3 0 3.3 2.5 -
Ref No.
MODE 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60
REC 2.5 3.2 0 1.7 0 0 0 3.3 0 3.3 1.1 - 0 0.3 1.5 3.3 0 - 1.0 4.8
PLAY 2.5 3.2 0 1.7 0 0 0 3.3 0 3.3 1.1 - 0 0.3 1.5 3.3 0 - 1.0 4.8
STOP 2.5 3.2 0 1.7 0 0 0 3.3 0 3.3 1.1 - 0 0.3 1.5 3.3 0 - 1.0 4.8
Ref No.
MODE 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80
REC 0 4.8 1.1 12.3 0 12.3 1.0 12.3 0 12.3 1.3 12.3 0 12.3 2.1 5.0 0 0 - -
PLAY 0 4.8 1.1 12.3 0 12.3 1.0 12.3 0 12.3 1.3 12.3 0 12.3 2.1 5.0 0 0 - -
STOP 0 4.8 1.1 12.3 0 12.3 1.0 12.3 0 12.3 1.3 12.3 0 12.3 2.1 5.0 0 0 - -
Ref No.
MODE 81 82 83 84 85 86 87 88
REC 000.330000
PLAY 0000.30000
STOP 0 0 0 0.3 0 0 0 0
P59001
P59001
P59001
P59001
P59001
84
DMR-EH57EC / DMR-EH57EP / DMR-EH57EE / DMR-EH575EG
