Panasonic DMR-EH57EC

15.2. Replacement Parts List
Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
*“(IA)-(IK)”, marks in Remarks indicate languages of
instruction manuals. [(IA): English, (IB): German, (IC):
Russian, (ID): Ukrainian, (IE): English, (IF): German, (IG):
Italian, (IH): Dutch, (II): French, (IJ): Spanish, (IK):
Swedish/Danish, (IL): Polish, (IM): Czech, (IN): Hungarian]
*Parts indicated with PAVC-CSG in the Remarks column
are supplied by PAVC-CSG.
*All parts except parts indicated with (PAVC-CSG) in the
Remarks column are supplied by PAVCSK.
Ref. No. Part No. Part Name &
Description
Pcs Remarks
n
nn
n RFKB79156BT MAIN P.C.B. 1 (RTL)EC
n
nn
n RFKB79156CT MAIN P.C.B. 1 (RTL)EP
n
nn
n RFKB79156AT MAIN P.C.B. 1 (RTL)EG
n
nn
n RFKB79156RT MAIN P.C.B. 1 (RTL)EE
C1501 ECJ2FB1A225K 10V 2.2U 1
C1502 F1H1H1030006 50V 0.01U 1
C1503 F2A1A681A870 10V 680P 1
C1504 F2A1C101B110 16V 100P 1
C1505 ECJ1VC1H221J 50V 220P 1
C1506 ECJ1VB1A105K 10V 1U 1
C1508 ECJ1VB1A105K 10V 1U 1
C1509 F1H1H1030006 50V 0.01U 1
C1510 ECJ1VB1A105K 10V 1U 1
C1511 ECJ1VB1A105K 10V 1U 1
C1512 ECJ1VB1A105K 10V 1U 1
C1516 F2A1H1510006 50V 150P 1
C1518 F2A0J681A833 6.3V 680P 1
C1521 F2A1C121A453 16V 120P 1
C1523 F2A1A470A388 10V 47U 1
C1524 F2A1A101A389 10V 100U 1
C1525 F1H1C104A042 16V 0.1U 1
C1526 ECJ1VB1A105K 10V 1U 1
C1527 ECJ1VB1A105K 10V 1U 1
C1528 F1K1C105A026 16V 1U 1
C1529 F2A1A470A388 10V 47U 1
C1535 ECJ1VB1A105K 10V 1U 1
C1536 F1J0J106A014 6.3V 10U 1
C1541 F2A1E1010067 25V 100U 1
C1545 F2A1C470B110 16V 47P 1
C1548 F2A1C121A453 16V 120P 1
C1549 F2A1C121A453 16V 120P 1
C1560 F2A0J101A825 6.3V 100U 1
C3001 F1H1C104A042 16V 0.1U 1
C3002 F1H1H1030006 50V 0.01U 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
C3003 F1H1C104A042 16V 0.1U 1
C3004 F1H1C104A042 16V 0.1U 1
C3005 F2A0J471A832 6.3V 470P 1
C3006 F2A0J471A832 6.3V 470P 1
C3007 F2A1A471A869 10V 470P 1
C3008 F2A1A101A868 10V 100U 1
C3009 F2A1A471A869 10V 470P 1
C3010 F2A1A101A868 10V 100U 1
C3011 F1H1C104A042 16V 0.1U 1
C3012 F2A1A471A869 10V 470P 1
C3013 F2A1A101A868 10V 100U 1
C3014 F1H1C104A042 16V 0.1U 1
C3015 F1H1C104A042 16V 0.1U 1
C3016 F1H1C104A042 16V 0.1U 1
C3017 F1H1C104A042 16V 0.1U 1 EE
C3018 F1H1C104A042 16V 0.1U 1
C3019 F1H1C104A042 16V 0.1U 1 EE
C3020 F1H1C104A042 16V 0.1U 1
C3021 F1H1C104A042 16V 0.1U 1 EE
C3022 F1H1C104A042 16V 0.1U 1
C3023 F1H1H330A736 50V 33P 1
C3025 F1H1C104A042 16V 0.1U 1
C3026 F1H0J1050012 6.3V 1U 1
C3027 F1H1C104A042 16V 0.1U 1
C3028 F1H0J1050012 6.3V 1U 1
C3029 F1H1C104A042 16V 0.1U 1
C3030 F1H0J1050012 6.3V 1U 1
C3031 F1H1H1030006 50V 0.01U 1
C3032 F2A0J101A167 6.3V 100U 1
C3033 F1H1H1030006 50V 0.01U 1
C3034 F1H1H1030006 50V 0.01U 1
C3035 F2A0J101A167 6.3V 100U 1
C3038 F1H1C104A042 16V 0.1U 1
C3039 F1H1C104A042 16V 0.1U 1
C3040 F1H1C104A042 16V 0.1U 1 EG,EC,EP
C3041 F1H1C104A042 16V 0.1U 1 EG,EC,EP
C3042 F1H1C104A042 16V 0.1U 1 EG,EC,EP
C3057 ECJ1VC1H471J 50V 470P 1 EE
C3058 ECJ1VC1H471J 50V 470P 1
C3059 ECJ1VC1H471J 50V 470P 1 EE
C3060 ECJ1VC1H471J 50V 470P 1
C3064 F1H1C104A042 16V 0.1U 1
C3065 F1H0J1050012 6.3V 1U 1
C3910 F2A1H100A236 50V 10U 1 EE
C3910 F2A1V100A534 35V 10U 1 EG,EC,EP
C3911 F2A1H100A236 50V 10U 1 EE
C3911 F2A1V100A534 35V 10U 1 EG,EC,EP
C3914 F2A1H100A236 50V 10U 1
C3915 F2A1H100A236 50V 10U 1
C3916 F2A1H1R0A236 50V 1U 1
C3917 F2A1H1R0A236 50V 1U 1
C3918 F2A1H100A236 50V 10U 1
C3919 F2A1H100A236 50V 10U 1
C3928 F2A1H1R0A638 50V 1U 1
C3929 F2A1H1R0A638 50V 1U 1
C3935 F2A1E2210050 25V 220U 1
C3951 F1H1H4700004 50V 47P 1
C3952 F1H1H4700004 50V 47P 1
C3953 ECJ1VC1H471J 50V 470P 1
C3954 ECJ1VC1H471J 50V 470P 1
C3955 F1H1H1010005 50V 100P 1
C3956 F1H1H1010005 50V 100P 1
C3957 ECJ1VC1H471J 50V 470P 1
C3958 ECJ1VC1H471J 50V 470P 1
C3959 F1H1H4700004 50V 47P 1
C3960 F1H1H4700004 50V 47P 1
C3961 F1H1H1010005 50V 100P 1
C3962 F1H1H1010005 50V 100P 1
C4005 F2A1H100A236 50V 10P 1 EE
C4006 F2A1H100A236 50V 10P 1 EE
C4008 F2A1E1010067 25V 100U 1
C4019 F2A1V100A534 35V 10U 1
C4021 F2A1V100A534 35V 10U 1
