Panasonic DMR-EH57EC

Ref. No. Part No. Part Name &
Description
Pcs Remarks
D4005 MA3Z142D0LG DIODE 1
D4006 MA3Z142D0LG DIODE 1
D7501 B0BA03600021 DIODE 1
D7502 B0JAMG000031 DIODE 1
D7504 MAZ4220NLF DIODE 1
D7505 B0AADM000003 DIODE 1
D7506 B0AADM000003 DIODE 1
D7507 B0JAMD000026 DIODE 1
D7508 MAZ4180NHF DIODE 1
D7510 MA2C165001VT DIODE 1
D7511 B0ACCK000005 DIODE 1
D7801 B0BA03000015 DIODE 1
DP7501 A2BB00000163 FL DISPLAY 1
FC7001 REZD0019 WIRE 1
IC1501 C0EBE0000550 IC 1
IC1506 C0DAEYH00002 IC 1
IC1510 C0DBEHE00005 IC 1
IC1520 C0CBCDC00052 IC 1
IC1521 C0CBCBD00048 IC 1
IC3001 C1AB00002379 IC 1
IC4001 C0DBAHD00013 IC 1
IC4009 C0ABBB000216 IC 1
IC4012 C0ABBB000230 IC 1
IC4901 B3ZAZ0000017 IC 1
IC7301 C0ZBZ0001081 IC 1 EG
IC7301 C1AB00002225 IC 1 EC,EP,EE
IC7302 C0EBH0000454 IC 1 EC,EP,EE
IC7401 C0CBCYG00004 IC 1
IC7402 C0CBCDC00052 IC 1
IC7403 C0CBCDC00052 IC 1
IC7404 RFKFM6016KT IC 1
IC7501 C2CBJG000737 IC 1
IC7503 C5HBZHC00001 IC 1
IC7504 C0HBB0000057 IC 1
IP1501 ERBSE3R00U IC PROTECTOR 1
IP7501 K5H751Z00003 IC PROTECTOR 1
IP7502 K5H751Z00003 IC PROTECTOR 1
IR7501 B3RAD0000137 REMOTE SENSOR 1
JK3001 K2HE109B0001 JACK,AV OUT 1 EG,EC,EP
JK3901 K1FB242B0007 JACK,AV2 1
JK3901 K2HE219B0004 JACK,AV OUT 1 EE
JK3903 K2HA304B0007 JACK,COMPONENT
VIDEO OUT
1
K3001 D0YBR0000020 1/10W 0 1 EE
K3002 D0YBR0000020 1/10W 0 1 EE
K3003 D0YBR0000020 1/10W 0 1 EE
K3004 D0YBR0000020 1/10W 0 1 EG,EC,EP
K3005 D0YBR0000020 1/10W 0 1 EG,EC,EP
K3006 D0YBR0000020 1/10W 0 1 EG,EC,EP
K3007 D0YBR0000020 1/10W 0 1
K4001 D0YBR0000020 1/10W 0 1 EG,EC,EP
K4002 D0YBR0000020 1/10W 0 1 EG,EC,EP
K7303 D0YBR0000020 1/10W 0 1 EC,EP,EE
K7306 D0YBR0000020 1/10W 0 1 EG
K7308 D0YBR0000020 1/10W 0 1 EG
K7503 D0YBR0000020 1/10W 0 1
K7506 D0YBR0000020 1/10W 0 1
K7509 D0YBR0000020 1/10W 0 1
K7513 D0YBR0000020 1/10W 0 1
K7516 D0YBR0000020 1/10W 0 1
K7517 D0YBR0000020 1/10W 0 1
K7801 D0YBR0000020 1/10W 0 1 EP,EG,EE
K7802 D0YBR0000020 1/10W 0 1 EC
K7803 D0YBR0000020 1/10W 0 1 EP,EG,EE
K7804 D0YBR0000020 1/10W 0 1 EP,EG,EE
Ref. No. Part No. Part Name &
Description
Pcs Remarks
L1504 G0A220GA0026 COIL 22UH 1
L1505 G0A100HA0023 COIL 10UH 1
L4901 G0C220JA0019 COIL 22UH 1
L7303 G0C1R0JA0019 COIL 1UH 1 EC,EP,EE
L7304 G0C3R9JA0019 COIL 1 EC,EP,EE
L7304 G0C470JA0019 COIL 47UH 1 EG
L7501 G0C390JA0055 COIL 39UH 1
L7502 G0C220JA0019 COIL 22UH 1
LB1501 D0YBR0000020 1/10W 0 1
LB1502 J0JKB0000003 COIL 1
LB1503 J0JKB0000003 COIL 1
LB1504 J0JKB0000003 COIL 1
LB1505 D0YBR0000020 1/10W 0 1
LB1506 J0JKB0000003 COIL 1
LB1507 J0JHC0000032 COIL 1
LB1510 J0JKB0000003 COIL 1
LB3001 J0JGC0000020 COIL 1
LB3002 J0JGC0000020 COIL 1
LB3003 J0JGC0000020 COIL 1
LB3005 J0JBC0000011 COIL 1 EE
LB3006 J0JBC0000011 COIL 1 EG,EC,EP
LB3006 J0JGC0000020 COIL 1 EE
LB3007 J0JBC0000011 COIL 1 EE
LB3008 J0JBC0000011 COIL 1 EG,EC,EP
LB3008 J0JGC0000020 COIL 1 EE
LB3907 J0JBC0000011 COIL 1
LB3908 J0JBC0000011 COIL 1
LB3911 J0JGC0000020 COIL 1
LB3912 J0JBC0000011 COIL 1
LB3913 J0JBC0000011 COIL 1
LB7301 J0JCC0000124 COIL 1 EC,EP,EE
LB7302 J0JCC0000124 COIL 1 EC,EP,EE
LB7303 J0JCC0000080 COIL 1 EC,EP,EE
LB7304 J0JHC0000032 COIL 1
LB7305 J0JCC0000080 COIL 1 EC,EP,EE
LB7402 J0JKB0000012 COIL 1
LB7403 J0JHC0000032 COIL 1
LB7404 J0JKB0000012 COIL 1
LB7405 J0JKB0000012 COIL 1
LB7406 J0JDC0000092 COIL 1
LB7407 J0JKB0000003 COIL 1
LB7409 J0JKB0000003 COIL 1
LB7411 J0JCC0000164 COIL 1
LB7412 J0JCC0000164 COIL 1
LB7413 J0JCC0000164 COIL 1
LB7414 J0JCC0000164 COIL 1
LB7415 J0JCC0000103 COIL 1
LB7416 J0JCC0000164 COIL 1
LB7417 J0JCC0000103 COIL 1
LB7418 J0JCC0000103 COIL 1
LB7419 J0JCC0000103 COIL 1
LB7420 J0JCC0000164 COIL 1
LB7421 J0JCC0000103 COIL 1
LB7422 J0JKB0000012 COIL 1
LB7509 J0JCC0000060 COIL 1
LB7801 J0JHC0000032 COIL 1
LB7802 J0JHC0000032 COIL 1
LB7803 J0JHC0000032 COIL 1
LB7804 J0JCC0000103 COIL 1
P1501 K1KA15A00118 CONNECTOR(15P) 1
P1503 K1KA04AA0180 CONNECTOR(4P) 1
P7402 K1KA88A00002 CONNECTOR(88P) 1
P7501 K1KA10A00258 CONNECTOR(10P) 1
P7502 K1KA03AA0301 CONNECTOR(3P) 1
Q1501 B1DHDC000027 TRANSISTOR 1
Q1502 2SD1819A0L TRANSISTOR 1
Q1509 B1DHED000008 TRANSISTOR 1
Q4006 2SD132800L TRANSISTOR 1
Q4007 2SD132800L TRANSISTOR 1
Q4008 2SD132800L TRANSISTOR 1
92
DMR-EH57EC / DMR-EH57EP / DMR-EH57EE / DMR-EH575EG
