Panasonic DMR-EH57EC

Ref. No. Part No. Part Name &
Description
Pcs Remarks
W746 D0YBR0000020 1/10W 0 1
W747 D0YBR0000020 1/10W 0 1
W748 ERJ6GEY0R00Z 1/8W 0 1
W749 ERJ6GEY0R00Z 1/8W 0 1
X7301 H0D245500016 CRYSTAL
OSCILLATOR
1 EC,EP,EE
X7301 H0H400400006 CRYSTAL
OSCILLATOR
1 EG
X7501 H0D100500018 CRYSTAL
OSCILLATOR
1
X7502 H0A327200108 CRYSTAL
OSCILLATOR
1
ZB7501 RMN0872 FL HOLDER(A) 1
ZB7502 RMN0873A FL HOLDER B 1
ZJ7401 K9ZZ00001279 EARTH PLATE 1
ZJ7402 K9ZZ00001279 EARTH PLATE 1
ZJ7403 K9ZZ00001279 EARTH PLATE 1
ZJ7404 K9ZZ00001279 EARTH PLATE 1
ZJ7405 K9ZZ00001279 EARTH PLATE 1
ZJ7406 K9ZZ00001279 EARTH PLATE 1
ZJ7423 K9ZZ00001279 EARTH PLATE 1
ZJ7501 K9ZZ00001279 EARTH PLATE 1
n
nn
n VEP70187A FRONT(L)P.C.B. (RTL)
S7002 EVQ11A04M SWITCH,POWER 1
n
nn
n VEP73146A FRONT JACK
P.C.B.
(RTL)
C3801 F1H1H1020005 50V 0.001U 1
C3803 F1H1H1020005 50V 0.001U 1
C3804 F1H1C104A042 16V 0.1U 1
JK3801 K2HA307A0009 JACK 1
JK3802 K1CB104A0017 JACK 1
JW3801 VWJ08H6074VV FLAT CABLE(8P) 1
LB3801 J0JBC0000011 COIL 1
LB3802 J0JBC0000011 COIL 1
LB3803 D0YBR0000020 1/10W 0 1
LB3804 D0YBR0000020 1/10W 0 1
LB3805 D0YBR0000020 1/10W 0 1
R3801 D0GB750JA057 1/10W 75 1
R3802 D0GB750JA057 1/10W 75 1
R3803 D0GB750JA057 1/10W 75 1
R3804 D0GB102JA057 1/10W 1K 1
ZJ3801 K9ZZ00001279 EARTH PLATE 1
ZJ3802 RMC0723 EARTH PLATE 1
n
nn
n VEP71118A POWER P.C.B. (RTL)
C1120 ECQU2A683MLC 100V 0.068U 1
C1121 ECQU2A223MLC 100V 0.022U 1
C1122 ECKWNA102MEV 250V 1000P 1
C1123 ECKWNA102MEV 250V 1000P 1
C1125 ECKWNA102MEV 250V 1000P 1
C1143 F2B2W4700003 450V 47U 1
C1150 F2A1V6800002 35V 68P 1
C1151 F1B3D102A011 2V 1000P 1
C1152 ECJ2VC1H331J 50V 330P 1
C1153 ECJGVB1H222K 50V 2200P 1
C1154 ECJGVB1H102K 50V 1000P 1
C1200 F1J1E104A081 25V 0.1U 1
C1201 ECJ2VB1E473K 25V 0.047U 1
C1270 F2A1C1820005 16V 1800P 1
C1271 F2A1C1820005 16V 1800P 1
C1272 F2A1C8210008 16V 820P 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
C1401 F2A0J1220028 6.3V 1200P 1
C1402 F2A0J3310059 6.3V 330U 1
C1601 F2A1E4710061 25V 470U 1
C1602 F1J1E104A081 25V 0.1U 1
C1603 F1J1E104A081 25V 0.1U 1
C1604 ECJ2YB1C474K 16V 0.47U 1
C1605 ECJ2VC1H181J 50V 180P 1
C1606 ECJGVB1H103K 50V 0.01U 1
C1607 F2A1A6810022 10V 680P 1
C1608 F1J1E104A081 25V 0.1U 1
C1800 F2A1E4700048 25V 47U 1
D1140 B0EDKT000009 DIODE 1
D1141 B0HADV000001 DIODE 1
D1151 B0HAGM000006 DIODE 1
D1152 MAZ4100NMF DIODE 1
D1155 MAZ73000BC DIODE 1
D1156 MA2C165001VT DIODE 1
D1157 B0HADV000001 DIODE 1
D1270 B0JBSG000048 DIODE 1
D1400 B0JANE000037 DIODE 1
D1601 B0JCPD000021 DIODE 1
D1602 B0JCPD000021 DIODE 1
D1701 MA22D3900L DIODE 1
D1702 MA22D3900L DIODE 1
D1703 MA22D3900L DIODE 1
D1800 MA2J11100L DIODE 1
F1101 K5D202BK0005 FUSE 1
IC1150 C0DACZH00017 IC 1
IC1200 C0DAEMZ00001 IC 1
IC1601 C0DBAZZ00132 IC 1
K1128 ERJ6GEY0R00Z 1/8W 0 1
L1120 G0B233D00001 COIL 1
L1121 G0B233D00001 COIL 1
L1270 G0A100K00003 COIL 10UH 1
L1400 G0A100HA0023 COIL 10UH 1
L1600 G0A100HA0023 COIL 10UH 1
L1601 G0A100K00003 COIL 1
LB1122 J0JKB0000003 COIL 1
LB1123 J0JKB0000003 COIL 1
LB1125 J0JHC0000048 FILTER 1
LB1126 ERJ6GEY0R00Z 1/8W 0 1
LB1600 J0JHC0000048 FILTER 1
P1101 K2AA2H000007 AC INLET 1
P1102 K1KB15AA0032 CONNECTOR(15P) 1
Q1200 B3PBA0000454 TRANSISTOR 1
Q1600 B1DHED000008 TRANSISTOR 1
QR1800 B1GDCFNN0002 TRANSISTOR 1
QR1801 B1GBCFNN0004 TRANSISTOR 1
R1122 ERG1SJ101E 1W 100 1
R1150 ERJ6GEYJ180V 1/8W 18 1
R1151 ERJ6GEYJ682V 1/8W 6.8K 1
R1152 ERJ6GEYJ103V 1/8W 10K 1
R1153 ERJ6GEYJ180V 1/8W 18 1
R1154 ERJ6GEYG822V 1/8W 8.2K 1
R1155 ERJ6GEYG471V 1/8W 470 1
R1156 ERJ6GEYG223V 1/8W 22K 1
R1157 ERJ6GEYG471V 1/8W 470 1
R1158 ERX2SJR22E 2W 22 1
R1200 ERJ6GEYG122V 1/8W 1.2K 1
R1201 ERJ6GEYG822V 1/8W 8.2K 1
R1205 ERJ6GEYJ224V 1/8W 220K 1
R1206 ERJ6GEYG242V 1/8W 2.4K 1
R1207 ERJ6GEYJ103V 1/8W 10K 1
95
DMR-EH57EC / DMR-EH57EP / DMR-EH57EE / DMR-EH575EG
