Panasonic DMR-EH57EC

Ref. No. Part No. Part Name &
Description
Pcs Remarks
R56137 ERJ2GE0R00X 1/16W 0 1
R56138 ERJ2GE0R00X 1/16W 0 1
R56140 ERJ2GEJ8R2X 1/16W 8.2 1
R56142 ERJ2GEJ330X 1/16W 33 1
R56143 ERJ2GEJ330X 1/16W 33 1
R56144 ERJ2GEJ8R2X 1/16W 8.2 1
R56145 ERJ2GEJ8R2X 1/16W 8.2 1
R56146 ERJ2GEJ8R2X 1/16W 8.2 1
R56147 ERJ2GEJ8R2X 1/16W 8.2 1
R56148 ERJ2GEJ8R2X 1/16W 8.2 1
R56149 ERJ2GEJ8R2X 1/16W 8.2 1
R56150 ERJ2GEJ8R2X 1/16W 8.2 1
R56158 ERJ2GEJ152X 1/16W 1.5K 1
R56159 ERJ2GEJ332X 1/16W 3.3K 1
R56160 ERJ2GEJ223X 1/16W 22K 1
R56161 ERJ2GEJ470X 1/16W 47 1
R56162 ERJ2GEJ103X 1/16W 10K 1
R56163 ERJ2GEJ103X 1/16W 10K 1
R56166 ERJ2GE0R00X 1/16W 0 1
R56167 ERJ2GEJ102X 1/16W 1K 1
RX56101 D1H8R0040009 RESISTOR-
RESISTOR
1
RX56102 D1H8R0040009 RESISTOR-
RESISTOR
1
VA56101 EZAEG2A50AX FILTER 1
VA56102 EZAEG2A50AX FILTER 1
VA56103 EZJZ0V80008B FILTER 1
VA56104 EZAEG2A50AX FILTER 1
VA56105 EZJZ0V80008B FILTER 1
VA56106 EZAEG2A50AX FILTER 1
VA56107 EZJZ0V80008B FILTER 1
VA56108 EZAEG2A50AX FILTER 1
VA56109 EZJZ0V80008B FILTER 1
VA56110 EZAEG2A50AX FILTER 1
VA56111 EZJZ0V80008B FILTER 1
VA56112 EZAEG2A50AX FILTER 1
VA56113 EZAEG2A50AX FILTER 1
n
nn
n VEP70194A ATAPI P.C.B. (RTL)
P9801 K1KB40A00124 CONNECTOR(40P) 1
P9802 K1MN40BA0173 CONNECTOR(40P) 1
n
nn
n CASING/ACCESSORY
/PACKING
1 RHD30113 SCREW 2 S
1 RHD30113-1K SCREW 2 K
2 RHD30119-L SCREW 14
3 RKM0552A-S TOP CASE 1 S
3 RKM0552A-K TOP CASE 1 K
4 RFKB79156BT MAIN P.C.B. 1 EC(RTL)
4 RFKB79156CT MAIN P.C.B. 1 EP(RTL)
4 RFKB79156AT MAIN P.C.B. 1 EG(RTL)
4 RFKB79156RT MAIN P.C.B. 1 EE(RTL)
4-1 RMC0625 TUNER GND 1
5 VEP70187A FRONT(L)P.C.B. 1 (RTL)
6 VEP73146A FRONT JACK
P.C.B.
1 (RTL)
7 VEP71118A POWER P.C.B. 1 (RTL)
8 VEP73147A DV JACK P.C.B. 1 (RTL)
9 VEP73148A HDMI P.C.B. 1 (RTL)
10 VEP70194A ATAPI P.C.B. 1 (RTL)
11 RHD30111-3 SCREW 16
12 RHD30102-1 SCREW 2
13 RMA2051 REAR ANGLE B 1
14 RMA2047 FRONT ANGLE 1
15 XSN3+4FJ SCREW 2
16 VMC1534 EARTH SPRING(T) 2
17 RHD30151 SCREW 2
18 RMA2052 DRIVE SPACER 1
19 RQLS0394 CAUTION LABEL 1
Ref. No. Part No. Part Name &
Description
Pcs Remarks
20 RSC0805 DIGITAL SHIELD 1
21 RHD30152 HDD SCREW 4
22 RMG0677-K DAMPER 4
23 RMN0874 HDD BRACKET 1
24 RFKV0092HDK HDD 160GB 1
25 RMX0382 HDD CUSHION 4
26 VEE0Z41 WIRE WITH
CONNECTOR
1
27 RGR0365J-B REAR PANEL 1 EC
27 RGR0365J-C REAR PANEL 1 EP
27 RGR0365J-A REAR PANEL 1 EG
27 RGR0365K-A REAR PANEL 1 EE
28 RKA0144-K FOOT RUBBER 4
29 RYP1371D-S FRONT PANEL
ASS’Y
1 ECS
29 RYP1371D-K FRONT PANEL
ASS’Y
1 ECK
29 RYP1371E-S FRONT PANEL
ASS’Y
1 EPS,EES
29 RYP1371E-K FRONT PANEL
ASS’Y
1 EPK
29 RYP1371C-S FRONT PANEL
ASS’Y
1 EGS
29 RYP1371C-K FRONT PANEL
ASS’Y
1 EGK
29-1 RKF0787N-S DOOR 1 ECS,EGS
29-1 RKF0787N-K DOOR 1 ECK,EGK
29-1 RKF0787P-S DOOR 1 EPS,EES
29-1 RKF0787P-K DOOR 1 EPK
29-2 RYF0813B-K TRAY DOOR ASS’Y 1
29-2-1 VMB3410 BLINDER SPRING 1
29-3 RYF0814B-K FL WINDOW ASS’Y 1
29-4 RMZ0911 FL BARRIER SHEET 1
30 VWJ1941 DIGITAL-HDD FFC 1
32 RMX0286 PCB SPACER 1
33 L6FAJDAE0002 FAN MOTOR 1
36 RMQ1612 HEAT TRANSFER
SHEET
1
37 RMQ1614 HEAT TRANSFER
SHEET
1
38 VMX1336 MINI CARD SPACER 1
39 RMX0361 PCB SPACER 1
40 RMX0393 FRONT SPACER 1
41 RFKNEH57EC RAM/DIGITAL
P.C.B. MODULE
1 EC
41 RFKNEH57EP RAM/DIGITAL
P.C.B. MODULE
1 EP
41 RFKNEH575EG RAM/DIGITAL
P.C.B. MODULE
1 EG
41 RFKNEH57EE RAM/DIGITAL
P.C.B. MODULE
1 EE
A1 K2KA6BA00003 AV CORD 1
A2 K1TWACC00001 RF COAXIAL CABLE 1
A3 N2QAYB000124 REMOTE CONTROL
ASS’Y
1 EC,EG
A3 N2QAYB000125 REMOTE CONTROL
ASS’Y
1 EP,EE
A3-1 100300035100 BATTERY COVER 1
A4 RJA0043-1C AC CORD 1
A5 RPQD0003 PAD (C) 1
A6 RPQFD0008 ACCESSORY BOX 1
A7 RPFD0005-1 POLYETHYLENE BAG 1
A8 RQT8881-1L OPERATING
INSTRUCTIONS
1 (IA)EG
A8 RQT8882-2D OPERATING
INSTRUCTIONS
1 (IB)EG
A8 RQT8909-R OPERATING
INSTRUCTIONS
1 (IC)EE
A8 RQT8910-Z OPERATING
INSTRUCTIONS
1 (ID)EE
A8 RQT8896-1L OPERATING
ISNTRUCTIONS
1 (IE)EC
A8 RQT8897-2D OPERATING
ISNTRUCTIONS
1 (IF)EC
A8 RQT8898-1V OPERATING
ISNTRUCTIONS
1 (IG)EC
97
DMR-EH57EC / DMR-EH57EP / DMR-EH57EE / DMR-EH575EG
