12
Control Panel
LCD Display
Indicates date and time, or
the current operation.
ON LINE Indicator
Blinks : When sending or
receiving faxes.
Used to select the FAX
mode.
Adjust the monitor and ringer volume.
(See page 15 to 16)
Move the cursor while entering numbers and
characters.
Search the station name for Directory
Search Dialling.
Confirm the entered station for multi-station
communication.
Select functions.
Confirm the current communication modes
(e.g. Page number, ID, Dialled Telephone
number, File number) when the unit is ON
LINE.
Used for the following:
Adjust the CONTRAST.
Used to select the
original size
manually.
Used to set Standard,
Fine, Super-Fine.
(See page 34)
To Next Page
