Hardware Description
FP Web-Server V2.11
18
2nd RS232C (SUB-D 9 male)
• Compatible to IBM PC serial port.
• Use standard serial computer cables.
a) Connects to modem (PPP) or
b) Transparent communication with 2
nd
PLC, computer, panel,
etc.
24V DC use Panasonic power cable
• brown = +24V DC
• blue = GND
• green = framing ground
