FP Web-Server V2.11
2.5 Technical Data
19
2.5 Technical Data
Feature Description: Type 1 Type 2
PN Hardware: FP-WEB PN Hardware: FP-WEB2 Product number
FP Web-Server:
PN Configurator: FPWEBTOOL2
PLC connection PLC COM: RS232C via 3-pin screw terminal port Plug: Phoenix product:
MC1,5/3-ST-3,5 Order Number: 18 40 37 9
Modem / 2nd RS232C
Modem COM: RS232C via 9-pin SUB-D port, with RTS, CTS Plug: 9-pin
SUB-D female
Power supply
24V DC Molex 35 plug on the bottom side of the unit
Ethernet connection Ethernet-COM: 10BASE-T via
RJ45 female connector
10BASE-T / 100BASE-TX autoneg
via RJ45 female connector
LEDs Power, Ethernet, PLC data
exchange
Power, Ethernet, Ethernet data, PLC
data
Protocols and standards TCP/IP, UDP/IP, DHCP, FTP, TELNET, http, SMTP, ESMTP-Auth, POP3,
PPP, IEC60870, NTP, Modbus, DynDNS
512KBytes 8MBytes Flash memory
For further information, refer to Available Memory Calculation in the online
help.
RAM 512KBytes 8MBytes
Operating voltage 24V DC (10.8 – 26.4V DC supplied by class 2 circuit only)
Current consumption Approx. 75mA at 24V DC Approx. 65mA at 24V DC
Degree of protection
IP20
Ambient temperature
0°C to +55°C
Storage temperature
-20°C to +70°C
Humidity:
Max. 30% to 85% (non-condensing)
Vibration resistance: 10Hz to 55Hz, 1 cycle per minute with a double amplitude of 0.75mm; 10
minutes every X-, Y-, and Z-axis
Shock resistance: Min. 10g; 4 times every X-, Y-, and Z-axis
Dimensions: Height 90mm, Width 25mm, Depth 64mm
Operating conditions: Free of corroding gases and excessive influence of dust
CE conformity: EMV Standard 89/336/EEC 1989EN 55022/Class B
EN 55022/Class B; EN 61000-4-2/A1; EN 61000-4-3
EN 61000-4-4; EN 61000-4-6
UL approval UL number "2LD7" (file
E232530)
UL under preparation
Hardware version Refer to hardware version (see page 15)
