Panasonic GT32-R

To Next Page

To Previous Page

4-19

4.4.2 RS485 Connection with FP0R COM Port

Connecting to the COM port

Usable models

PLC

PLC communication cable

Programmable display

FP0R

RS485 type

Loose-wire cable

5 V DC

24 V DC

RS422/RS485 type

Connecting to the COM port of FP0R
