6-10
6.3 GT02L
6.3.1 General Specifications (GT02L)
Item
Specifications
Rated voltage
5 V DC
Operating voltage range
4.5 to 5.5 V DC
Power consumption
1W or less (200 mA or less)
Note1)
Ambient temperature
0 to +50 C
Ambient humidity
20 to 85% RH (at 25 C), non-condensing
Storage temperature
-20 to +60 C
Storage humidity
10 to 85% RH (at 25 C), non-condensing
Breakdown voltage
Between [power supply terminals] and [case]
500 V AC for 1 minute, Cutoff current 10mA (at default setting)
Insulation resistance
Between [power supply terminals] and [case]
100 M or more, 500 V DC, measured with megohmmeter (at default
setting)
Vibration resistance
5 to 8.4 Hz half amplitude 3.5 mm,
8.4 to 150 Hz acceleration 9.8 m/s
2
,
10 sweeps each in X, Y and Z directions (1 octave/min)
Shock resistance
147 m/s
2
, 3 times on 3 axes
EC Directive applicable
EN61131-2 (EMC Directive)
Noise immunity
1000 V [P-P] or more, Pulse width 50 ns, 1s between power supply
terminals (based on in-house measurements)
Note2)
Protective construction
IP65 (Initial value, evaluated by us)
Dustproof and drip-proof from front panel only (packing used on panel
contact surface)
Note3)
Weight
Approx. 150 g
Note1) When supplying the power from the TOOL port of a PLC (CPU unit), confirm the PLC restrictions
such as the power supply capacity before use.
Note2) When using our exclusive cable.
Note3) When reattaching, replace waterproof packing.
