4-4
4.2 RS232C Connection
4.2.1 Difference of Terminal blocks Between GT Models
Although the terminal blocks vary according to the GT models, the connection method is the same.
The connection diagram for 24 V DC is described with the terminal blocks other than the one for GT01.
24 V DC type
other than GT01
24 V DC-type GT01
5 V DC-type GT01
5 V DC-type GT02/GT02L
