6-14
6.4 GT03-E
6.4.1 General Specifications (GT03-E)
Item
Specifications
GT03M-E
GT03T-E
Rated voltage
24 V DC
Operating voltage range
21.6 to 26.4 V DC
Power consumption
1.9 W or less (80 mA or less)
3.1 W or less (130 mA or less)
Ambient temperature
-20 to +60 C
Note1)
Ambient humidity
20 to 85% RH (at 25 C), non-condensing
Storage temperature
-20 to +60 C
Storage humidity
10 to 95% RH (at 25 C), non-condensing
Breakdown voltage
Between [power supply terminals] and [case]
500 V AC for 1 minute, Cutoff current 10mA (at default setting)
Insulation resistance
(Operating voltage: 500
V DC)
Between [power supply terminals] and [case]
100 M or more (at default setting)
Vibration resistance
Conforms to JISB3502 and IEC61131-2.
5 to 8.4 Hz half amplitude 3.5 mm
8.4 to 150 Hz, Acceleration 9.8 m/s
2
10 sweeps each in X, Y and Z directions (1 octave/min)
Shock resistance
Conforms to JISB3502 and IEC61131-2.
147 m/s
2
3 times on 3 axes
EU Directive applicable
EN61131-2 (EMC Directive)
Noise immunity
1000 V [P-P] or more, Pulse width 50 ns, 1s between power supply
terminals (based on in-house measurements)
Note2)
Electrostatic discharge
resistance
6 kV
(Contact discharge, IEC61000-4-2 Level 3)
Protective construction
IP67 (Initial value, evaluated by us)
Dustproof and drip-proof from front panel only (packing used on panel
contact surface)
Note3)
Weight
Approx. 170 g
Note1) When it is installed in horizontal orientation (installed to make the liquid crystal face be topside),
installed upright in vertical orientation or when using a battery, the usable range is -20 to +55 C.
Note2) When using our exclusive cable.
Note3) When reattaching, replace waterproof packing.
