Character Name, Function, Setting range Default value
Data bit/Parity selection
7 bits/Even parity
[22]
• Selects the data bit and parity.
Not available if the Serial communication option is not added or if Contact input option is
added.
• : 8 bits/No parity
: 7 bits/No parity
: 8 bits/Even parity
: 7 bits/Even parity
: 8 bits/Odd parity
: 7 bits/Odd parity
Stop bit selection
1
[23]
• Selects the stop bit.
Not available if Serial communication option is not added or if Contact input option is added.
• : 1
: 2
Communication response time setting
5ms
[24]
• Sets the minimum response time of communication.
Not available if Serial communication option is not added or if Contact input option is added.
• Setting range: 5 to 99ms
