Panasonic KT4H - Modbus Commands: Control, Input, and Action Settings; Modbus Commands for SV Rise;Fall Rate; Modbus Command for Control Output OUT;OFF; Modbus Command for Auto;Manual Control

54
Modbus
function code
Data item Data
03H/06H 0033H SV rise rate Set value, Decimal point ignored
03H/06H 0034H SV fall rate Set value, Decimal point ignored
03H/06H 0037H Control output OUT/OFF
0000H: Control output ON
0001H: Control output OFF
03H/06H 0038H Auto/Manual control
0000H: Automatic control
0001H: Manual control
03H/06H 0039H Manual control MV Set value
03H/06H 0040H Alarm 1 Energized/Deenergized 0000H: Energized
0001H: Deenergized
03H/06H 0041H Alarm 2 Energized/Deenergized 0000H: Energized
0001H: Deenergized
03H/06H 0044H Input type
0000H: K -200 to 1370
0001H: K -200.0 to 400.0
0002H: J -200 to 1000
0003H: R 0 to 1760
0004H: S 0 to 1760
0005H: B 0 to 1820
0006H: E -200 to 800
0007H: T -200.0 to 400.0
0008H: N -200 to 1300
0009H: PL- 0 to 1390
000AH: C(W/Re5-26) 0 to 2315
000BH: Pt100 -200.0 to 850.0
000CH: JPt100 -200.0 to 500.0
000DH: Pt100 -200 to 850
000EH: JPt100 -200 to 500
000FH: K -320 to 2500
0010H: K -320.0 to 750.0
0011H: J -320 to 1800
0012H: R 0 to 3200
0013H: S 0 to 3200
0014H: B 0 to 3300
0015H: E -320 to 1500
0016H: T -320.0 to 750.0
0017H: N -320 to 2300
0018H: PL- 0 to 2500
0019H: C (W/Re5-26) 0 to 4200
001AH: Pt100 -320.0 to 1500.0
001BH: JPt100 -320.0 to 900.0
001CH: Pt100 -320 to 1500
001DH: JPt100 -320 to 900
001EH: 4 to 20mA -2000 to 10000
001FH: 0 to 20mA -2000 to 10000
0020H: 0 to 1V -2000 to 10000
0021H: 0 to 5V -2000 to 10000
0022H: 1 to 5V -2000 to 10000
0023H: 0 to 10V -2000 to 10000
03H/06H 0045H Direct/Reverse action
0000H: Reverse action
0001H: Direct action
03H/06H 0047H AT bias Set value
03H/06H 0048H ARW Set value
03H/06H 0049H Heater burnout alarm 2 value Set value, Decimal point ignored
