Panasonic KV-S1057C - Location of Controls; Main Unit; Front

Main Unit
Front
1
2
3
5
4
678
9
10
11
12
14
13
Document guides
Mixed batch card guide
Manual feed selector
Switches the scanning method between continuous scanning (Auto) and manual scanning (Manual).
Operation panel
For details, refer to "Operation Panel and LED Indicators" (page 14).
Exit tray
Exit extension tray 1
Exit extension tray 2
Exit stopper
Exit guides
Fan exhaust vent
ADF door
ADF door release
Feed tray
Feed extension tray
