Panasonic KX-TDA0108

3.2 Connection
Installation Manual 215
3.2 Connection
3.2.1 Connection
Serial Interface Connection
Note
For pin assignments and maximum cabling distance, refer to "2.11.1 Connection of Peripherals".
LAN Connection via CTI-LINK Card
Note
For pin assignments and maximum cabling distance, refer to "2.6.7 CTI-LINK Card".
PC
USB Port
To USB Port
To COM Port
RS-232C Port
PC
PC
Switching Hub
To network port
RJ45
