2.2 Installation of the Hybrid IP-PBX
Installation Manual 65
2.2.13 Floor Standing (KX-TDA200 Only)
1. Install 4 anchor plugs in the floor, using the metal bracket as a template. Fix the metal bracket with 4
screws (A).
2. Remove the front cover of the cabinet (refer to "2.2.3 Opening/Closing the Front Cover").
Anchor Plug
Hammer
30 mm
6.5 mm
Metal
Bracket
Screw (A)
Floor
Screw (A) Metal Bracket
Anchor
Plug
TOP
