1.4 Specifications
30 Installation Manual
1.4.3 System Capacity
Maximum Optional Service Cards
There are 2 types of optional service cards for installation:
• Cards installed in the slots of the Hybrid IP-PBX
• Cards mounted on other optional service cards
Notes
• Any card that exceeds the capacity of the Hybrid IP-PBX will be ignored.
• When the Hybrid IP-PBX starts up with an invalid configuration, some cards will be ignored.
Cards Installed in the Slots of the Hybrid IP-PBX
MPR Card Slot
Free Slots 1 to 5
Free Slots 1 to 10
MPR Card Slot
Option Card Slot
Option Card Slot
KX-TDA100 KX-TDA200
