Panasonic KX-TDA0108

4.1 Troubleshooting
230 Installation Manual
5 Sub Code Five-digit sub code (1XXYY)
1: Cabinet number
XX: Slot number
KX-TDA100: 00 to 06 (00: MPR slot; 01 to 05: Free slot; 06: Option
slot)
KX-TDA200: 00 to 11 (00: MPR slot; 01 to 10: Free slot; 11: Option
slot)
YY: Physical port number (01 to 16)
For OPB3 card, sub slot number + port number will be displayed.
Sub slot 1: 11 to 14
Sub slot 2: 21 to 24
Sub slot 3: 31 to 34
Note
When there is no parameter for slot and physical port number, XX
and YY will be displayed as "00".
Example: Sub code for MPR card = 10000
6 Error Message Error description
Item Description
