Panasonic KX-TDE200 Features Guide

1.26 Administrative Information Features
Feature Guide 303
1.26 Administrative Information Features
1.26.1 Station Message Detail Recording (SMDR)
Description
Automatically records detailed information for each extension.
1. SMDR Output Port
The Serial Interface (RS-232C) port can be used to output the SMDR data.
The following devices can be connected:
• Serial Interface (RS-232C) port: PC, printer, etc.
2. SMDR Output Data
[General]
The following data will be recorded and sent to the SMDR output port:
a) Trunk call information (incoming/outgoing)
b) Intercom call information (outgoing)
c) Log-in/Log-out information
d) PBX error log (→ 2.4.3 Local Alarm Information)
e) Hospitality feature information (→ 1.27.1 Hospitality Features—SUMMARY)
f) Printing Message information (→ 1.26.2 Printing Message)
Memory for SMDR: A specified number of call records can be stored in the PBX. If more calls are
originated or received, the oldest record is overwritten by the newest one.
With KX-TDA100/KX-TDA200/KX-TDA600, when an EMEC/MEC card is installed, the number of
SMDR records that can be stored will increase.
3. SMDR Format Type and Contents
The following three types of output format can be selected through system programming:

Panasonic KX-TDE200 Specifications

General

LED indicators	Yes
SIP extensions	128
Number of extensions	256
Number of DECT cell stations	32

Weight and Dimensions

Weight	15966.5 g
Dimensions (WxDxH)	424 x 276 x 439 mm
