2.3 System Data Control
420 Feature Guide
2.3.4 Quick Setup
Description
It is possible to set up the basic PBX parameters using a PC. When a PC accesses the PBX for the first time
with the Installer Level Programmer Code (→ 2.3.1 PC Programming), Quick Setup display will appear
automatically. The following items can be programmed as desired:
Note that the programmable items may vary depending on the version of KX-TDA Maintenance Console
being used.
Item Parameter Description
Date & Time Year/Month/Date/Hour/
Minute
The date and time set on the PC will be used.
System Password 4–10 characters Enter the system password for installer (→ 2.3.3
Password Security).
Operator & Manager Extension Number Assign the PBX operator to all time modes (day/
lunch/break/night) (→ 2.2.5 Operator Features). The
extension assigned as the PBX operators is
automatically allowed to perform manager operation
(→ 2.2.6 Manager Features).
Flexible Numbering
Feature
1. Type 1
(with )
2. Type 2
(without )
If "Type 1 (with )" is selected, " " must prefix all
feature numbers (except access numbers) when an
extension user wants to use a feature.
[Example] Call Pickup feature number
Type 1 (with ): 41
Type 2 (without ): 41
For default of the flexible numbers, refer to the
[Flexible Numbering Table (available while a dial tone
is heard)] (→ 2.3.6 Flexible Numbering/Fixed
Numbering).
Extension KX-TDA30/KX-TDA100/
KX-TDA200: from 101/
from 201
KX-TDA600: from 1001/
from 2001
Determines the number from which default extension
numbers begin.
Operator 0/9 The feature number for Operator Call can be
selected.
CO Access 0/1/9 The feature number for Idle Line Access can be
selected.
Remote Maintenance
Number
Remote Maintenance
Dial Number
Enter the complete telephone number of the PBX
(including the country code). When necessary, this
number will be used to access the PBX from a remote
location for maintenance purposes.
To Next Page
