2.4 Fault Recovery/Diagnostics
436 Feature Guide
2.4.3 Local Alarm Information
Description
When a PBX error occurs and the PBX detects it, the System Alarm button light on the PT of an extension,
which is allowed to use this feature through system programming (a maximum of two extensions per PBX),
turns on red. Pressing the button will show the error number on the display. If multiple errors occur, the error
number will be displayed in order of highest priority to lowest. The System Alarm button light turns off
automatically after all error numbers have been displayed.
For details about the errors and their solutions, refer to the Installation Manual.
[Error Example]
[Explanation]
Conditions
• System Alarm Button
A flexible button can be customised as the System Alarm button.
• If an extension allowed to utilise this feature uses PC Console or PC Phone, the alarm information will
be displayed on the PC, and can be sent to the preprogrammed destination via PC Console or PC
Phone. PC Console and PC Phone use e-mail to send the information.
• The alarm information will be recorded on SMDR, if enabled through system programming.
• The PBX can be automatically diagnosed at a preprogrammed time everyday.
Installation Manual References
KX-TDA30
4.1.5 Troubleshooting by Error Log
KX-TDA100/KX-TDA200
4.1.5 Troubleshooting by Error Log
Number in the
Example
Item Description
(1) Error Code Shows 3-digit error code.
(2) Sub Code Shows five-digit sub code (XYYZZ).
X: Shelf number (1–4)
YY: Slot number (00–11)
ZZ: Physical port number (01–16)
ERR #100 (10000)
(1)
(2)
