Panasonic KX-TG1283JXS

Ref.
No.
Part No. Part Name & Description Remarks
IC2 PQLP10263Z RF UNIT
X1 H0D103500003 CRYSTAL OSCILLATOR
29.1.3. Operational P.C.Board Parts
Ref.
No.
Part No. Part Name & Description Remarks
PCB2 PQWP21233JXH OPERATIONAL P.C.BOARD ASS´Y
(RTL)
(TRANSISTORS)
Q901 PQVTDTC143E TRANSISTOR(SI) S
Q902 PQVTDTC143E TRANSISTOR(SI) S
Q903 PQVTDTC143E TRANSISTOR(SI) S
(LEDS)
LED901 PQVDBR1111C LED S
LED902 LNJ308G8JRA LED
LED903 PQVDBR1111C LED S
(RESISTORS)
R901 ERJ3GEYJ561 560
R902 ERJ3GEYJ820 82
R903 ERJ3GEYJ181 180
(CONNECTOR)
CN901 K1MN30B00031 CONNECTOR
(OTHERS)
E1 L5DCBCB00017 LIQUID CRYSTAL DISPLAY
E2 PQHS10327Z TAPE LCD
E3 PQHR11102Z GUIDE LCD PS-HB
E4 PQJE10145Z LEAD WIRE FFC
29.2. Handset
29.2.1. Cabinet and Electrical Parts
Ref.
No.
Part No. Part Name & Description Remarks
101 PQGP10272Z1 PANEL LCD (for KX-TCA122CXS)
(for KX-TCA121CXS)
AS-HB
101 PQGP10272Z3 PANEL LCD (for KX-TCA122CXT)
(for KX-TCA121CXT)
AS-HB
102 PQHS10673W TAPE DOUBLE SIDED
103 PQKM10647W8 CABINET BODY (for KX-
TCA122CXS)
ABS-HB
103 PQKM10647W0 CABINET BODY (for KX-
TCA122CXT)
ABS-HB
103 PQKM10647Y1 CABINET BODY (for KX-
TCA121CXS)
ABS-HB
103 PQKM10647Y3 CABINET BODY (for KX-
TCA121CXT)
ABS-HB
104 PQGT18182Z NAME PLATE (for KX-TCA122CXS)
104 PQGT18182X NAME PLATE (for KX-TCA122CXT)
104 PQGT17789Z NAME PLATE (for KX-TCA121CXS)
104 PQGT17789X NAME PLATE (for KX-TCA121CXT)
105 PQHS10705Z SPACER LCD CUSHION
106 PQBC10413Z1 BUTTON NAVI KEY ABS-HB
107 PQBC10414Y1 BUTTON SP PHONE ABS-HB
108 PQSX10274Z KEYBOARD SWITCH (for KX-
TCA122CXS)(for KX-TCA121CXS)
108 PQSX10274X KEYBOARD SWITCH (for KX-
TCA122CXT)(for KX-TCA121CXT)
109 PQHS10467Z COVER SP NET
110 L0AD02A00015 SPEAKER
111 PQHR11104Z GUIDE SPEAKER ABS-HB
112 PQWE10034Z BATTERY TERMINAL
113 PQJT10216Z CHARGE TERMINAL (R)
114 PQJT10217Z CHARGE TERMINAL (L)
115 PQHR11059Z GUIDE SPEAKER ABS-HB
116 PQHG10702Z RUBBER PARTS SPEAKER
117 L0AD02A00010 SPEAKER
118 PQHS10622Z COVER SP NET
119 PQJC10056Y BATTERY TERMINAL
120 PQKF10630X1 CABINET COVER (for KX-
TCA122CXS)(for KX-TCA121CXS)
ABS-HB
120 PQKF10630X3 CABINET COVER (for KX-
TCA122CXT)(for KX-TCA121CXT)
ABS-HB
Ref.
No.
Part No. Part Name & Description Remarks
121 PQHX11356Z PLASTIC PARTS BATTERY COVER
SHEET (for KX-TCA122CXS/CXT)
121 PQHX11299Z PLASTIC PARTS BATTERY COVER
SHEET (for KX-TCA121CXS/CXT)
122 PQHS10561Y SPACER BATTERY COVER
123 PQKK10583Z1 LID BATTERY COVER (for KX-
TCA122CXS)(for KX-TCA121CXS)
ABS-HB
123 PQKK10583Z3 LID BATTERY COVER (for KX-
TCA122CXT)(for KX-TCA121CXT)
ABS-HB
29.2.2. Main P.C.Board Parts
Note:
(*1) When replacing IC1 or IC3, data need to be written to
them with PQZZTG1283JX. Refer to Handset (P.41) of
THINGS TO DO AFTER REPLACING IC.
(*2) When replacing the Handset LCD, see HOW TO
REPLACE THE HANDSET LCD (P.17).
Ref.
No.
Part No. Part Name & Description Remarks
PCB100 PQWPG1233JXR MAIN P.C.BOARD ASS´Y (RTL)
(for KX-TG1283JXS/JXT)
PCB100 PQWPCA122CXR MAIN P.C.BOARD ASS´Y (RTL)
(for KX-TCA121CXS/CXT)
(ICs)
IC1 C1CB00002038 IC (BBIC) (*1)
IC3 PQWI2A130EXR IC (EEPROM) (*1)
(TRANSISTORS)
Q1 PQVTFDN335N TRANSISTOR(SI) S
Q2 B1ADGE000004 TRANSISTOR(SI)
Q3 B1ADGE000004 TRANSISTOR(SI)
Q4 B1ADGE000004 TRANSISTOR(SI)
Q5 B1ABCF000103 TRANSISTOR(SI)
Q7 PSVTDTC143X TRANSISTOR(SI) S
Q8 PSVTDTC143X TRANSISTOR(SI) S
Q9 UN9219J TRANSISTOR(SI) S
Q10 B1ABCF000103 TRANSISTOR(SI)
Q11 B1ABCF000103 TRANSISTOR(SI)
(DIODES)
D1 B0JCME000035 DIODE(SI)
D4 MA8047 DIODE(SI) S
D5 MA8047 DIODE(SI) S
D6 B0BC2R1A0006 DIODE(SI)
D7 MA2Z72000 DIODE(SI)
LED1 LNJ308G8JRA LED
LED2 LNJ308G8JRA LED
LED3 LNJ308G8JRA LED
LED4 LNJ308G8JRA LED
LED5 LNJ308G8JRA LED
LED6 LNJ308G8JRA LED
LED7 LNJ308G8JRA LED
LED9 PQVDBR1111C LED S
(COILS)
L1 G1C470M00025 COIL
L4 G1C100MA0072 COIL
L5 G1C100MA0072 COIL
L9 PQLQR2M33NKT COIL S
F1 PQLQR2M5N6K COIL S
(RESISTORS)
R1 ERJ6RSJR10V 0.1
R5 ERJ3GEYJ471 470
R6 ERJ2GEJ103 10K
R7 ERJ2GEJ224 220K
R12 ERJ3GEYJ393 39K
R15 ERJ3GEYJ100 10
R19 ERJ3GEYJ565 5.6M
R20 ERJ2GEJ102 1K
R21 ERJ2GEJ102 1K
R25 ERJ2GEJ331 330
R26 ERJ2GEJ331 330
R29 ERJ3GEYJ222 2.2K
R37 ERJ3GEY0R00 0
