Panasonic KX-TG1283JXS

Ref.
No.
Part No. Part Name & Description Remarks
R38 ERJ3GEY0R00 0
R39 ERJ2GEJ103 10K
R40 ERJ2GEJ103 10K
R43 ERJ6RSJR10V 0.1
R46 ERJ3GEYJ562 5.6K
R47 ERJ3GEYJ562 5.6K
R54 ERJ2GE0R00 0
R57 ERJ3GEYJ680 68
R59 ERJ2GE0R00 0
R60 ERJ2GEJ101 100
R61 ERJ2GEJ102 1K
R63 ERJ2GEJ103 10K
R64 ERJ2GEJ103 10K
R68 ERJ2GEJ682 6.8K
R69 ERJ3EKF8203 820K
R70 ERJ3EKF4303 430K
R71 ERJ3GEYJ221 220
R72 ERJ2GEJ102 1K
R73 ERJ3GEYJ104 100K
R75 ERJ2GEJ102 1K
R81 ERJ2GEJ4R7 4.7
R82 ERJ3GEYJ101 100
R83 ERJ6GEY0R00 0
R85 ERJ2GEJ330 33
R86 ERJ3GEYJ330 33
R87 ERJ2GEJ181 180
R88 ERJ2GEJ181 180
R89 ERJ2GEJ181 180
R90 ERJ3GEYJ684 680K
R91 ERJ2GEJ104 100K
R92 ERJ3GEY0R00 0
R95 ERJ3GEY0R00 0
R96 ERJ2GEJ103 10K
R97 ERJ2GE0R00 0
L6 ERJ6GEY0R00 0
L7 ERJ6GEY0R00 0
L8 ERJ3GEY0R00 0
(CAPACITORS)
C1 EEE0GA331WP 330
C3 ECUV1C104KBV 0.1
C4 ECUV1H100DCV 10P
C5 ECST0JY106 10
C6 ECUV1H080DCV 8P
C7 ECUV1H150JCV 15P
C8 ECUV1A224KBV 0.22
C10 ECUV1C104KBV 0.1
C12 ECUV1A105KBV 1
C17 ECUV1H100DCV 10P
C18 ECJ0EB1H102K 0.001
C19 F1G1A1040003 0.1
C20 F1G1A1040003 0.1
C21 F1G1A1040003 0.1
C22 F1G1A1040003 0.1
C23 F1G1A1040003 0.1
C24 F1G1A1040003 0.1
C27 ECUV1A105KBV 1
C28 ECUV1A105KBV 1
C30 ECUV1A105KBV 1
C31 ECUV1A105KBV 1
C32 ECUV1A105KBV 1
C33 ECUV1A105KBV 1
C34 ECUV1A105KBV 1
C35 ECUV1A105KBV 1
C37 F1G1A1040003 0.1
C39 ECUV1A105KBV 1
C40 ECST0JY106 10
C44 ECJ0EC1H100D 10P
C45 ECJ0EB1H102K 0.001
C46 ECJ0EC1H100D 10P
C47 ECJ0EC1H020C 2P
C48 ECJ0EC1H100D 10P
C49 ECJ0EC1H020C 2P
C50 ECJ0EC1H100D 10P
Ref.
No.
Part No. Part Name & Description Remarks
C51 ECJ0EC1H100D 10P
C52 ECUV1C104KBV 0.1
C53 ECJ0EC1H151J 150P
C54 ECJ0EC1H100D 10P
C55 ECJ0EC1H020C 2P
C57 EEE0JA331P 330
C58 ECUV1C104KBV 0.1
C60 ECUV1A475KB 4.7
C62 ECJ0EC1H220J 22P
C63 ECUV1A475KB 4.7
C66 ECUV1H020CCV 2P
C68 F1G1A1040003 0.1
C69 ECUV1H100DCV 10P
C70 ECUV1H100DCV 10P
C71 ECJ0EC1H100D 10P
C72 F1G1A1040003 0.1
C78 PQCUV1H100DC 10P S
C79 PQCUV1H100DC 10P S
C84 ECJ0EB1H102K 0.001
C87 ECUV1H100DCV 10P
C91 ECJ0EC1H100D 10P
C93 ECUV1H101JCV 100P
C94 ECUV1H101JCV 100P
C95 PQCUV1H100DC 10P S
C97 ECUV1H100DCV 10P
C98 ECUV1A475KB 4.7
C100 ECJ0EC1H100D 10P
C103 ECUV1H100DCV 10P
C104 ECUV1A105KBV 1
C107 ECUV1H101JCV 100P
C108 ECJ0EC1H100D 10P
C109 ECJ0EC1H100D 10P
C111 ECJ0EC1H101J 100P
C112 ECJ0EC1H101J 100P
C113 ECUV1H101JCV 100P
C114 ECJ0EC1H100D 10P
C115 ECJ0EC1H100D 10P
C116 ECJ0EC1H100D 10P
C117 ECJ0EC1H100D 10P
C118 ECUV1H103KBV 0.01
C119 F1G1A1040003 0.1
C120 F1G1A1040003 0.1
C121 ECUV1H102KBV 0.001
C122 ECUV1A105KBV 1
C123 ECUV1H100DCV 10P
(OTHERS)
MIC L0CBAB000052 MICROPHONE
E101 PQHR11088Y GUIDE, LCD
E102 PQHR11092Z TRANSPARENT PLATE, LCD PLATE
E103 PQHX11289Z COVER, LCD COVER SHEET
E104 L5DCADC00013 LIQUID CRYSTAL DISPLAY (*2)
E105 PQWEA144EXR PLASTIC PARTS, TAPE
E106 PQSA10159Z ANTENNA
CN6 PQLP10263Z RF UNIT
X1 H0D103500007 CRYSTAL OSCILLATOR
29.3. Charger Unit
29.3.1. Cabinet and Electrical Parts
Ref.
No.
Part No. Part Name & Description Remarks
200 PQLV30032ZS CHARGER UNIT (for KX-
TCA121CXS)
200 PQLV30032ZT CHARGER UNIT (for KX-
TCA121CXT)
200-1 PQGG10276Z1 GRILLE (for KX-TCA121CXS) PC-HB
200-1 PQGG10276Z3 GRILLE (for KX-TCA121CXT) PC-HB
200-2 PQKM10656Z1 CABINET BODY (for KX-
TCA121CXS)
ABS-HB
200-2 PQKM10656Z3 CABINET BODY (for KX-
TCA121CXT)
ABS-HB
200-3 PQHR11085Z CASE CHARGE TERMINAL
200-4 PQKE10384Z1 HOLDER CHARGE TERMINAL (R) POM-HB
76
KX-TG1283JXS / KX-TG1283JXT / KX-TCA122CXS / KX-TCA122CXT / KX-TCA121CXS / KX-TCA121CXT
