Panasonic Lumix DC-GH5 User Manual

7. Recording Motion Pictures
170
∫ Conditions for outputting a time code to HDMI output
A time code is output to video from the HDMI output only when all the following conditions
are satisfied.
Applicable modes:
Display the microphone level on the recording screen.
Settings: [ON]/[OFF]
• When [Mic Level Limiter] is set to [OFF], [Mic Level Disp.] is fixed to [ON].
Applicable modes:
Adjust the sound input level to 19 different levels (j12 dB to i6dB).
• Displayed dB values are approximate.
Applicable modes:
The camera adjusts the sound input level automatically, minimising the sound distortion
(crackling noise) when the volume is too high.
Settings: [ON]/[OFF]
In recording
• When [HDMI Time Code Output] is set to
[ON].
• In Creative Video Mode.
• When [Rec Format] is set to [AVCHD], [MP4
(LPCM)] or [MOV].
In playback
• When [HDMI Time Code Output] is set to
[ON].
• When playing back a motion picture recorded
with Creative Video Mode.
• When [HDMI Mode (Play)] in [TV Connection]
is set to [AUTO].
Displaying/setting the sound input level
[Mic Level Disp.]
> [Motion Picture] > [Mic Level Disp.]
[Mic Level Adj.]
> [Motion Picture] > [Mic Level Adj.]
[Mic Level Limiter]
> [Motion Picture] > [Mic Level Limiter]
MENU
MENU
MENU

Panasonic Lumix DC-GH5 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Video Format	MOV, MP4
Battery Life	Approx. 410 shots (CIPA standard)
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
ISO Range	200-25600
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	12 fps
Video Recording	4K up to 60p
Internal Recording	4:2:2 10-bit
Viewfinder	OLED Live View Finder, 3, 680k dots
Screen	3.2"
Autofocus System	Contrast Detect DFD
Image Stabilization	5-axis sensor-shift
Memory Card Slots	Dual SD/SDHC/SDXC (UHS-II compatible)
Connectivity	Wi-Fi, Bluetooth, HDMI, USB 3.1
Battery	DMW-BLF19 (Lithium-ion)
Weight	Approx. 725 g (with battery and memory card)
