Panasonic Lumix DC-GH5 User Manual

7. Recording Motion Pictures
172
Applicable modes:
Display colour bars and output a test tone.
1 Select the menu. (P55)
• Colour bars will be displayed and a test tone will be output.
• You can set the test tone level from among three options (s12 dB, s18 dB, and s20 dB)
by rotating the control dial.
• If you press the motion picture button, the colour bars and the test tone will be recorded as
a motion picture.
2 Press [MENU/SET] to exit the menu.
Displaying colour bars/Outputting a test tone
> [Motion Picture] > [Color Bars]
[SMPTE] [EBU] [ARIB]
Colour bars compliant with
SMPTE
Colour bars compliant with
EBU
Colour bars compliant with
ARIB
• The brightness and colour tone that appear on the camera’s monitor or viewfinder may differ
from those that appear on another device such as an external monitor.
Check the final picture quality on another device such as an external monitor.
Not available in these cases:
• This function is not available in the following cases:
– When [4K Live Cropping] is set
MENU

Panasonic Lumix DC-GH5 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Video Format	MOV, MP4
Battery Life	Approx. 410 shots (CIPA standard)
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
ISO Range	200-25600
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	12 fps
Video Recording	4K up to 60p
Internal Recording	4:2:2 10-bit
Viewfinder	OLED Live View Finder, 3, 680k dots
Screen	3.2"
Autofocus System	Contrast Detect DFD
Image Stabilization	5-axis sensor-shift
Memory Card Slots	Dual SD/SDHC/SDXC (UHS-II compatible)
Connectivity	Wi-Fi, Bluetooth, HDMI, USB 3.1
Battery	DMW-BLF19 (Lithium-ion)
Weight	Approx. 725 g (with battery and memory card)
