Panasonic Lumix DC-GH5 User Manual

2. Getting Started/Basic Operations
36
When recording into strong backlight, irregular reflection may occur within the lens. The
lens hood reduces the inclusion of unwanted light in the recorded images and lowers the
drop in contrast. The lens hood cuts off excess lighting and improves the picture quality.
To attach the lens hood (flower shape) that came with the interchangeable lenses
(H-ES12060/H-FS12060/H-HSA12035)
Hold the lens hood by placing your fingers as
shown in the figure.
• Do not hold the lens hood in such a way that it will be
bent.
1 Align the mark A ( ) on the lens hood with the
mark on the tip of the lens.
2 Rotate the lens hood in the direction of the
arrow until it clicks and then align the mark B
( ) on the lens hood with the mark on the tip
of the lens.
∫ Removing the lens hood (H-ES12060)
Rotate the lens hood in the direction of the arrow
while pushing the button C on the lens hood.
Attaching the Lens Hood

Panasonic Lumix DC-GH5 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Lens Mount	Micro Four Thirds
Video Format	MOV, MP4
Battery Life	Approx. 410 shots (CIPA standard)
Dimensions	138.5 x 98.1 x 87.4 mm
Sensor Size	17.3 x 13 mm
ISO Range	200-25600
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	12 fps
Video Recording	4K up to 60p
Internal Recording	4:2:2 10-bit
Viewfinder	OLED Live View Finder, 3, 680k dots
Screen	3.2"
Autofocus System	Contrast Detect DFD
Image Stabilization	5-axis sensor-shift
Memory Card Slots	Dual SD/SDHC/SDXC (UHS-II compatible)
Connectivity	Wi-Fi, Bluetooth, HDMI, USB 3.1
Battery	DMW-BLF19 (Lithium-ion)
Weight	Approx. 725 g (with battery and memory card)
