268
Connecting with other devices
Viewing on TV screen
Preparation
Turn off both camera and TV.
1
Connect camera to TV
Check the plug direction and insert it straight in. (If the cable is inserted in the wrong
direction, the plug could become deformed and cause faulty operation.) Also, do not
insert into the wrong socket. Doing so may cause damage to this unit.
HDMI micro cable
Use a “High Speed HDMI micro cable” with the HDMI logo.
Cables that do not comply with the HDMI standards will not work.
“High Speed HDMI micro cable” (Type D - Type A plug, up to 2 m (6.6 feet) long)
[HDMI] socket
To HDMI video/audio input socket
2
Turn on the TV and switch the TV input source to match the
connection socket
3
Turn on the camera and press [ ] (Playback) button
●
Bars may appear at the sides or at the top and bottom of the screen, depending on the aspect
ratio setting.
●
Change the screen mode on your TV if the picture is displayed with the top or bottom cut off.
●
Check the [HDMI Mode (Play)]. (→206)
●
Pictures are not displayed on the camera screen. Also, sound is not produced from the camera’s
speaker.
●
HDMI output will be canceled if a USB connection cable (supplied) is connected simultaneously.
●
Read the operating instructions for the TV.
