Panasonic Lumix DMC-GF6 User Manual

21
Preparation
Changing the Lens
By changing the lens, you will increase your picture taking-options and further your
enjoyment of the camera. Change the lens using the following procedure.
•
Check that the camera is turned off.
• Change lenses where there is not a lot of dirt or dust. Refer to P326 when dirt or dust gets on
the lens.
Align the lens fitting marks A and then rotate the lens in the direction of
the arrow until it clicks.
• Do not press the lens release button B when you attach a lens.
• Do not try to attach the lens when holding it at an angle to the camera body as the lens mount
may get scratched.
• Be sure to remove the lens cap when recording.
• Do not insert your fingers into the mount when the lens and body cap
are removed from the camera body.
• To prevent dust or debris from adhering to internal parts of the
camera body, fit the body cap or a lens to the mount on the camera
body.
• To prevent scratching of the contact points, fit the lens rear cap to the
lens when it is unattached or fit the lens to the camera body.
• It is recommended to attach the lens cap or attach the MC Protector
(optional) to protect the lens surface when carrying. (P290)
Attaching the lens
Preparations: Remove the lens rear cap from the lens.
•
If the body cap is fitted to the camera, remove it.

Panasonic Lumix DMC-GF6 Specifications

General

Megapixel	16 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	16.68 MP
Image sensor size	4/3 \
Image formats supported	JPEG XR, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image stabilizer location	Lens
Still image resolution(s)	4608x3456, 3264x2448, 2336x1752, 1824x1368, 4608x3072, 3264x2176, 2336x1560, 1824x1216, \\r 4608x2592, 3264x1840, 1920x1080, 1824x1024, 3456x3456, 2448x2448, 1744x1744, 1712x1712
Filter size	46 mm
Digital zoom	4 x
Optical zoom	2 x
Focal length range	14 - 42 mm
Lens mount interface	Micro Four Thirds (MFT)
Maximum aperture number	22
Minimum aperture number	3.5
Number of diaphragm blades	7
Number of aspheric elements	2
Lens structure (elements/groups)	9/8
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Spot Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.00625 s
Flash guide number	6.3 m
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1920x1080@25fps, 1920x1080@50fps, 640x480@25fps
Audio system	stereo
Audio formats supported	AAC
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
PictBridge	-
USB version	2.0
HDMI version	1.3c
HDMI connector type	Mini
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Children, Night, Portrait, Sunset, Landscape (scenery)
Photo effects	Skin tones, Solarisation
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Incandescent, Shade
Shooting modes	Aperture priority, Manual, Program, Scene, Shutter priority
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Battery voltage	7.2 V
Battery capacity	1025 mAh
Product color	Brown
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB

Weight and Dimensions

Depth	38.4 mm
Width	111.2 mm
Height	64.8 mm
Weight	281 g
Lens length	49 mm
Lens weight	110 g
Lens diameter	56 mm
Weight (including battery)	323 g
