Panasonic LUMIX DMC-GX8 User Manual

151
5. Focus and Brightness (Exposure) Settings
Position and size of the AF area can be changed.
1 Press 2 ().
2 Select [š] or [Ø] and press 4.
•
AF area setting screen is displayed.
• You can also display the AF area setting screen by
touching the screen.
3 Change the position and size of the AF area.
•
If you set the AF area over an eye in the yellow frame when [š] is selected, the eye to be
in focus will be changed. (P146)
4 Press [MENU/SET] to set.
•
AF area with the same function as [Ø] is displayed in the touched position, when the [š]
is selected.
Setting of the AF area is cleared when [MENU/SET] is pressed or [ ] is touched.
The 49 AF areas are divided into groups, each consisting of 9
areas (on the edge of the screen, 6 or 4 areas).
1 Press 2 ().
2 Select [ ] and press 4.
•
AF area setting screen is displayed.
3 Press 3/4/2/1 to select an AF area group.
•
You can also select a group by touching the screen.
4 Press [MENU/SET] to set.
•
Only [i] display (center point of selected group) will remain on
the screen.
• Setting of the AF area frame is cleared when [MENU/SET] is
pressed or [ ] is touched.
When selecting [š], [Ø]
Button
operation
Touch
operation
Description of operation
3/4/2/1 Touching Moves the AF area.
Pinching out/in Enlarges/reduces the AF area in small steps.
s Enlarges/reduces the AF area in large steps.
[DISP.] [Reset]
Resets the AF area back to the center.
• If you press the button again, the frame size will
be reset to the default setting.
When selecting [ ]
Examples of group

Panasonic LUMIX DMC-GX8 Specifications

General

Camera type	MILC Body
Sensor type	MOS
Image stabilizer	Yes
Total megapixels	21.77 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	5184 x 3888 pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	5184 x 3888, 3712 x 2784, 2624 x 1968, 1824 x 1368, 5184 x 3456, 3712 x 2480, 2624 x 1752, 1824 x 1216, 5184 x 2920, 3840 x 2160, 1920 x 1080, 1824 x 1024, 3888 x 3888, 2784 x 2784, 1968 x 1968, 1712 x 1712
Digital zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Single Auto Focus
Closest focusing distance	0.3 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/8000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Forced on, Red-eye reduction, Second curtain synchro, Slow synchronization
Flash sync-speed	1/250 s
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Flash exposure correction	±3EV (1/3 EV step)
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080, 3840 x 2160 pixels
Video formats supported	AVCHD, MP4
Maximum video resolution	3840 x 2160 pixels
Analog signal format system	NTSC, PAL
Resolution at capture speed	640x480@30fps, 1280x720@30fps, 1920x1080@30fps, 1920x1080@60fps, 3840x2160@24fps, 3840x2160@30fps
Audio system	Mono
Memory slots	1
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1040000 pixels
Magnification	0.77 x
Viewfinder type	Electronic
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Eye relief	21 mm
Scene modes	Panorama, Portrait, Landscape (scenery)
Image editing	Crop, Rotating
Photo effects	Black&White, Sepia, Vivid
White balance	ATW, Auto, Cloudy, Daylight, Flash, Halogen, Shade
Camera playback	Movie, Single image, Slide show, Thumbnails
GPS (satellite)	No
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3, RAW
Diopter adjustment (D-D)	-4 - 3
Power source type	Battery
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Product color	Black
Cables included	USB

Weight and Dimensions

Depth	61.3 mm
Width	133.2 mm
Height	77.9 mm
Weight	435 g
Lens length	63.6 mm
Lens weight	165 g
Lens diameter	60.6 mm
Weight (including battery)	487 g
