Panasonic LUMIX DMC-GX80 User Manual

101
4. Focus, Brightness (Exposure) and Colour tone Settings
When selecting [ ]/[ ]/[ ]
When selecting [ ]/[ ]/[ ]
Drag your finger over the parts you want to set as AF
areas.
•
If you touch one of the selected AF areas, the selection of
the area will be cancelled.
Press 3/4/2/1 to select the AF area, and then press [MENU/SET] to set (repeat).
•
The setting is cancelled when [MENU/SET] is pressed again.
• If you press [DISP.], all the selections will be cancelled.
6 Press [Fn1].
∫ Registering the set AF area to [ ], [ ]
or []
1 On the screen in step 3 on P100, press 3.
2 Press 3/4 to select a destination to which the setting will be registered, and
press [MENU/SET].
•
Turning off this unit will return the setting adjusted with [ ]/[]/[] back to the default
setting.
Button operation
Touch
operation
Description of
operation
3/4/2/1 Touching
Moves the
position
/ Pinching in/out
Changes the size
(3 levels)
[DISP.] [Reset]
Restores the
default setting
Touch operation
Button operation
ヤヒ
ヤビ
ヤピ
ヤヒ ヤビ ヤピ

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
