Panasonic LUMIX DMC-GX80 User Manual

71
3. Recording Modes
Taking Pictures by Specifying the Aperture/
Shutter Speed
Recording Mode:
•
The effects of the set aperture value and shutter speed will not be visible on the recording
screen. To check on the recording screen, please use [Preview]. (P75)
• The brightness of the screen and the recorded pictures may differ. Check the pictures on the
playback screen.
• Rotate the front/rear dial to display the Exposure Meter. Unsuitable areas of the range are
displayed in red.
• If the exposure is not adequate, the aperture value and the shutter speed turn red and blink
when the shutter button is pressed halfway.
(Example: In Manual
Exposure Mode)
A Exposure meter
B Aperture value
C Shutter speed
Aperture
value
Small
It becomes easier to
defocus the
background.
Large
It becomes easier to
maintain focus as far as
the background.
Shutter
speed
Slow
It becomes easier to
express movement.
Fast
It becomes easier to
freeze movement.
F
1258
5.64.0 8.0 11
603015
3030305.6
00 +3
SSSS SSSS
A
CB

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
