Panasonic LUMIX DMC-GX80 User Manual

301
11. Connecting to other equipment
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to
be printed out and instruct that printing be started on the camera’s monitor.
•
Group pictures will not be displayed as group pictures but as single pictures.
• Some printers can print directly from the card removed from the camera. For details, refer to
the operating instructions of your printer.
Preparations:
Turn on the camera and the printer.
Perform the print quality and other settings at the printer before printing the pictures.
1
Press [(] on the camera.
2
Connect the printer and camera with the USB connection cable
(supplied).
• Check the direction of the terminals and plug in/out straight holding onto the plug.
(It may result in malfunction by the deforming of the terminal if it is plugged in obliquely
or in wrong direction.)
Do not connect devices to incorrect terminals. Doing so may cause malfunction.
• Do not use any other USB connection cables except the supplied one.
A [CHARGE] socket
B USB connection cable (supplied)
3
Press 3/4 to select [PictBridge(PTP)], and then press [MENU/SET].

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
