Panasonic LUMIX DMC-GX80 User Manual

2. Getting Started/Basic Operations
32
Attaching/Removing the Lens
By changing the lens, you will increase your picture taking-options and further your
enjoyment of the camera.
•
Check that the camera is turned off.
• When attaching or detaching the interchangeable lens (H-FS12032/H-FS35100), retract the
lens barrel.
• Change lenses where there is not a lot of dirt or dust. Refer to P329 when dirt or dust gets on
the lens.
• Attach the lens cap.
While pressing on the lens release button A,
rotate the lens toward the arrow until it stops
and then remove.
• Hold the part around the base of the lens to rotate it.
• When the lens is removed from the camera body, make sure to attach the body cap to the
camera body and attach the lens rear cap to the lens.
• If the lens rear cap is fitted to the lens, remove it.
• If the body cap is fitted to the camera, remove it.
Align the lens fitting marks B and then rotate the lens in the direction of the arrow
until it clicks.
•
Do not press the lens release button C when you attach a lens.
• Do not try to attach the lens when holding it at an angle to the camera body as the lens mount
may get scratched.
Detaching the lens
Attaching the lens

Panasonic LUMIX DMC-GX80 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	16 megapixels
Image Processor	Venus Engine
Image Stabilization	5-axis in-body image stabilization
Built-in Flash	Yes
External Flash	Hot shoe
Dimensions	122 x 70.6 x 43.9 mm
Sensor Size	17.3 x 13.0 mm (Four Thirds)
ISO Sensitivity	200-25600
Autofocus System	Contrast AF
Viewfinder	Electronic (2.764M dots)
Screen	3.0" LCD (1.040K dots), tilting touchscreen
Video Recording	4K UHD at 30p/24p
Shutter Speed	1/16000 to 60 sec
Continuous Shooting	8 fps (AFS/MF), 6 fps (AFC)
Connectivity	Wi-Fi
Battery Life	Approx. 290 shots (CIPA standard)
Battery	Rechargeable Li-ion Battery Pack, 7.2V, 1025mAh
Weight	426 g (body only)
